The Icron USB Ranger 2244 (00-00264) is a four port USB 2.0 high speed
extension solution, enabling USB 2.0 connections at up to 480Mbps over 10km /
16.2 miles of singlemode fiber optics. The Ranger 2244 provides a remote four
port USB 2.0 powered hub delivering standard 500mA power and supporting all USB
device types, including Isochronous web cams.
The USB Ranger 2244 (00-00264), and the Ranger 2200 family of products are
powered by ExtremeUSB, enabled by Icron’s LionsGate USB Extension ASIC.
ExtremeUSB provides true USB 2.0 extension at up to 480Mbps over a variety of
media, without the need of additional software drivers. A true plug-and-play
solution, the Ranger 2244 is compatible with all leading operating systems, and
supports all USB device types from high-speed web cams, hard drives, printers,
scanners, audio devices, touch screens, digital cameras and game controllers.
Ranger 2244 replaces the Ranger 444 fiber optic extender, adding support for USB
1.1 classic hosts and addressing the adverse operating environments ideal for
ExtremeUSB®. The system is FCC Class B certified, meets EN-61000 16kV ESD
immunity and is housed in a robust metal enclosure.
Icron USB Ranger 2244 (00-00264) Function Diagram
Icron USB Ranger 2244 (00-00264) Features & Benefits:
Extends USB 2.0 high-speed and USB 1.1 (low speed, full speed) dvices up
to 100m over Cat5 cable.
Supports all USB device types: control, interrupt, bulk and isochronous
at up to 480Mbps.
True plug and play, ready to operate right out of the box. No new driver
installation required.
Supports all major operating systems including Windows, Mac OS, and
Linux.
Integrated hub provides four remote USB 2.0 ports. Number of devices can
be increasing using additional USB hubs.
Remote unit provides standard 500mA to each USB
port.
Power adapter at local unit is not required for normal operation.
Ideal for a wide variety of USB devices from: printers, scanners, hard
drives, and audio devices to touch screens, web cams, and game controllers.
