The Avocent SwitchView MM2 4SVPUA20-001 is a 4-port PS/2 2.0 USB switch system/console USB 2.0 hub with audio.
The SwitchView MM Desktop KVM switches enable you to use a single keyboard, monitor and mouse to seamlessly access multiple PCs, without the expense and waste of valuable desktop real estate.
Avocent 4SVPUA20 Features:
Affordable and Easy to Install – Switching solutions for today’s home offices and small office
Compact, Space-Saving Appliances – Eliminate desktop clutter and provide efficient PC access
Share Speakers and a Microphone – Between PCs
PC access: Access from two PCs from a single keyboard, monitor and mouse
Audio support: Audio feature enables you to share speakers and a microphone between attached PCs
Ease of use: Pushbutton or keyboard hotkeys for channel selections; auto scanning allows easy monitoring of attached computers
Hot-plug capability: You can add or remove a desktop PC or laptop without turning off the switch or other attached servers
Avocent 4SVPUA20 Specifications:
Mechanical
Height
1.7 in. (4.3 cm)
Width
8.7 in. (22.09 cm)
Depth
4.0 in. (10.16 cm)
Weight
2 lbs. (.90 kg)
Environmental
Operating Temperature
32 to 104 F (0 to 40 C)
Storage Temperature
-4 to 140 F (-20 to 60 C)
Power
Operating Power
5V
Power Frequency
60 Hz
Input Power
DC9V
Supported Hardware
Computers
PS2 or USB 2.0
Monitor
(VGA, SVGA, XGA, QVGA, SXGA, UXGA, QXGA) Maximum resolution of 2048x1536
Peripherals
USB 2.0 Keyboard and Mouse, PS/2 Keyboard and Mouse
Ports/Cables
PC Ports
4
Hub Ports
2-USB 2.0
Cables Included
None
Standards
Approved Agencies
FCC Class B, UL C-UL, CE, VCCI Class A
