  • FDX-Mini - SmartAVI FDX-Mini - Click To Enlarge

Extension of any DVI-D, USB Keyboard, Mouse, and RS232 Signal up to 1,400 Feet

FDX-Mini

$699.00
FREE Shipping on orders over $100

 For reliable, uninterrupted and long-distance DVI-D KVM extension, the FDX-Mini provides the best solution with its fiber optic extension capabilities. Users can bridge large gaps that they ordinarily could not with this compact device. The FDX-Mini includes the transmitter and receiver, for complete point-to-point signal extension, with no need for any other hardware or software. Using FDX-Mini technology, this fiber DVI extender is capable of sending a DVI-D signal up to 1,400 feet (426.7 meters) over a conventional and inexpensive multimode fiber cable. Supported resolutions up to 1920x1200x60Hz. As with all DVI-D and USB connections, the signals are transmitted via the extender. The FDX-Mini also has USB keyboard, mouse, and RS-232 support, giving you the ability to control your displays or devices remotely

 Features:

  • Top Signal Quality at Maximum Extension Over Multimode Fiber (1,400 ft.)
  • Superior Image Quality at all Resolutions
  • Video Resolutions up to 1920 x 1200 at 60Hz (1280 x 1024 at 75Hz)
  • Customizable/Programmable DDCTable
  • Supports USB Keyboard/Mouse
  • Supports DVI-D
  • SRS232 at 9600bps
  • Fiber PlugType LC
  • CompatibleWith all Operating Systems
  • CompatibleWith all Major KVM Switches
  • Compact Metal Casing

Applications:

  • Corporate or Educational Presentations
  • Financial (Remote Servers/User Control)
  • Call Centers
  • Industrial (Long-RangeWorkstation Isolation)
  • Information Terminals/Kiosks
  • Airport Installations (Air Traffic Control/Passenger Information)
  • KVM Extension where Exceptional Quality of Signal is Crucial
  • Medical (Remote Operation Away from Sensitive/Magnetic Equipment)
  • Recording (for Large Studios where Editing/ Mixing Stations are Compact and/or Require Complete Silence)

Diagram

diagram

Specifications:

Video
Format  HDMI 1.4
Maximum Pixel Clock   300 MHz
Input Interface   (8) HDMI (female)
Output Interface  (1) HDMI (female)
Other
USB USB Keyboard and Mouse Compliant
 Fiber Extender Fiber
225m @ Multimode 62,5μ
450m @ Multimode 62,5μ
Fiber-Plug type LC
 RS-232  Data up to 9600bps
Weight  2 lbs.
Dimensions  4.5x5.5x1.70



UPC / EAN Barcode icon
UPC 813280017657
EAN 0813280017657
