Rose Vista L-series 4-Port KVM Switch

KVL-4UA/OV-K

$449.00$402.95
Save $46.05
FREE Shipping on orders over $100

Rose Vista L-series 4-port KVM switch with on-screen menu and DB25 connectors. Includes two 5' and two 10' cables and rack mount.

Rose Vista L-series Switch Kit Features and Benefits

  • Low cost
  • Chassis size: 13" wide, rack mountable 4-port, expandable to 64 computers
  • Two 5' and two 10' cables included
  • Connectors available in two styles:
    • DB25 connectors, uses Rose UltraCable, supports USB
    • PC connectors, uses native connectors for keyboard, video, and mouse
  • Works with all PCs and most UNIX workstations
  • USB support on DB25 models (with UltraCables)
  • Supports wheel and serial mice
  • Select computer from front panel or from easy to use keyboard commands
  • Front panel LEDs show computer selected, power status, and activity
  • Powered by your computer, no external power supply required
  • Scan mode sequences through computers at adjustable rate
  • Non-volatile memory stores configuration settings
  • Rack mountable (rack mounts included)
  • Made in USA

The Rose Vista Advantage

The Rose Vista L-series models are primarily intended for server racks. They can be rack mounted, and are 1U high. They have high resolution video and are available in PC and multi-platform versions. The multi-platform version supports the Apple ADB interface and is available in DB25 only. Each port is programmable as PC or Apple. This model is available with the on-screen display (OSD) option. The OSD option allows you to configure the switch from the OSD and to program the names of your computers. When you switch to a computer, the name of the computer is shown in programmable color and position. You can also select a computer by name and switch to it. The OSD has a built-in screen saver and many other features.

Keyboard and Mouse: All Vista models support full emulation of keyboard and mouse. It works with major operating systems such as Windows, Linux, and UNIX running on workstations such as SGI, IBM RS/6000, HP 9000, Dec Alpha, and others. All models support PS/2, PS/2 wheel, or serial mice. This model does not support a physical serial mouse. When using the DB25 models with USB cables, you can use PC-USB, Apple-USB, or Sun-USB.

Video: All Vista models have very high resolution capability and support VGA video beyond 1600 x 1280 non-interlaced. Keyboard, mouse, and video signals can be driven up to 1000 feet using our CrystalView extenders.

Rose Vista L-series Switch Kit Specifications
Dimensons/Weight

  13.3" W x 4.8" D x 1.75" H / 4 lbs (1U)
33.8 W x 12.2 D x 4.4 H (cm) / 1.8 kg
Input Power Supply   Supplied by computers; optional power available
Video Resolution   1920 x 1440
Connectors




  Video: HD 15 Female VGA Video
Keyboard: MiniDin-6F
Mouse: MiniDin-6F
CPU PC models: HD15F/MiniDin-6F/MiniDin-6F
DB25 models: DB25 Female
Rack mount   19", 23", or 24"
Chassis

  Fully shielded, black painted steel with polyester graphic overlay panel
Controls

  Computer Select Switch: 1-8 (varies by model)
Status LED, shows keyboard-mouse activity
Indicators

  Computer select LEDs 1-8 (varies by model)
Computer power LEDs 1-8 (varies by model)
Environmental   0°- 55°C, 0%-80% non-condensing relative humidity
Approvals   CE
