Rose MEC-8U2V MultiVideo 8-Port, Dual Video, Multi-Platform KVM

Show Order

KVM Switch Product Selector
WHAT THEY'RE SAYING
Yahoo User Ratings for KVM Switches Online PriceGrabber User Ratings for KVM Switches Online KVM Switches Online is a BBB Accredited Business. Click for the BBB Business Review of this Internet Services in Broomfield CO
SECURE SHOPPING
McAfee SECURE sites help keep you safe from identity theft, credit card fraud, spyware, spam, viruses and online scams KVM Switches Online offers secure, 128bit shopping


Home >> Single-User KVMs >> 8 Port Single User KVMs >> Rose MEC-8U2V
Share |
MEC-8U2V - Rose MEC-8U2V - MEC-8U2V - Click To Enlarge

MEC-8U2V

Part # MEC-8U2V
Price:$1,999.00
Sale Price:
$1,677.48
Savings:$321.52

Related Accessories
RM-UC19 - Rose 19" Rack Mount Kit (2U Chassis)

Rose Rackmount Kit RM-UC19
$43.35
RM-UC23 - Rose 23" Rack Mount Kit (C Chassis)

Rose Rack Mount Kit RM-UC23
$43.35
RM-UC24 - Rose 24" Rack Mount Kit (C Chassis)

Rose Rack Mount Kit RM-UC24
$43.35
Product Description

The Rose MultiVideo MEC-8U2V delivers keyboard command switching between different multi-platform CPUs that are sending multiple video signals. With the rose MEC-8U2V a user can easily switch between eight computers to view dual video outputs per CPU. Daisy chain MultiVideo units to support up to multi-platform 64 CPUs.

The MEC-8U2V uses simple keyboard commands to switch between computers. The optional on-screen display (call 1-877-586-6654 for availability and pricing) allows switching from the streamlined highly customizable visual interface.

The MEC-8U2V's high resolution capabilities make it ideal for many diverse applications including financial trading, emergency call centers, television studios, medical imaging, video editing, process control, and CAD/CAM to name just a few.

Combine the MEC-8U2V with Rose's ViewLink or CrystalView extenders and extend the local console up to 10 km (approx. 6 miles) away.

Rose MultiView Application

Features and Benefits

  • 8 computers, each with 2 video ports
  • Video resolution up to 1600 x 1280
  • Integrated expansion for chaining units together supports up to 64 computers
  • The Multi-platform MEC-8U2V converts PC, UNIX, Apple, or Sun keyboard and mouse data to any platform
  • Optional advanced on-screen display (OSD) for configuration, computer selection, security, on-screen names, and screen savers (call 1-877-586-6654 for availability and pricing)
  • Switch computers from keyboard, front panel, optional OSD, or RS232 port
  • Scan mode switches through computers with adjustable rate
  • Easy to use keyboard shortcut switches computer or turns scan mode on/off
  • Supports HV sync, composite sync, and sync-on-green
  • Free firmware upgrades for product enhancements and new Software features available
  • Rack mount kits available in 19?, 23?, and 24? sizes
  • Made in USA



MPC-U2V Specifications

Mechanical
Width16.7 in. (42.4 cm.)
Height3.5 in. (8.9 cm.)
Depth4.85 in. (12.3 cm.)
Weight7 lbs. (1.8 kgs.)
Computer Connections8
Port SelectionKeyboard, Front Panel, RS232 Port or Optional OSD
Connectors
Console PortsDB25 Female
KVM PortsDB25 Female
PowerIEC 320 standard receptacle
RS232RJ 6 Conductor
Video PortsDB25

ControlsLighted Power On / Off Switch
Video Specifications
Bandwidth250 MHz
SyncAccepts HV, composite, and sync-on-green

IndicatorsLEDs: Power, 4-16 select, 4-16 CPU power
VideoVideo resolution up to 1600 x 1280
ApprovalsUL, cUL, TUV, CE
PowerAuto Switching, 90 - 240 VAC, 60 watts
Environment
Operating Temperature0-55C
Humidity5-80% RH, Non-condensing
Physical Properties
HousingElectro galvanized steel, black powder coated


Recommended Accessories
PictureDescriptionPart #PriceAdd To Cart
RM-UC19Rose Rackmount Kit RM-UC19
2U, 19" Rack Mount Kit
RM-UC19$43.35

RM-UC23Rose Rack Mount Kit RM-UC23
23" Rack Mount Kit (C Chassis)
RM-UC23$43.35

RM-UC24Rose Rack Mount Kit RM-UC24
24" Rack Mount Kit (C Chassis)
RM-UC24$43.35
