2-port Secure EAL4+ KVM, Dual-Monitor HDMI 1.4 to DVI-I (dual-link) & DisplayPort 1.2, Audio

SC920XD-001

$1,516.00$1,070.12
Save $445.88

End-Of-Life (EOL)
For stock: Contact Us
Replaced by: Vertiv SC920DPH-400

Ports: 2 Computer Ports
Video Type: HDMI 1.4 to DVI-I (Dual-Link) & DisplayPort 1.2
Video Output: Dual Monitor
Features: Audio

Vertiv Cybex SC920XD Manual (PDF)

The Cybex SC920XD secure desktop KVM is designed to meet the stringent specifications of the U.S. government and comply with the requirements of the latest NAIP protection profile for peripheral sharing devices version 3.0. The SC920XD delivers proven security features such as unidirectional data diode technology, which assures complete network isolation while offering user-friendly, easy switching between sources. An active anti-tampering system and holographic tampering evident labels alert the user when the system has been physically compromised. Patented emulation technology prevents Display Data Channel (DDC) signal leakage; and guards against signal attacks.

Industry-leading security features are complemented with a range of capabilities and productivity features that make the Cybex SC920XD a great investment. Experience true image reproduction with support for HDMI 1.4, which delivers resolutions up to UHD 4K (3840X2160 @ 30). NUM Lock, CAPS Lock and Scroll Lock indicators improve user interaction while maintaining unidirectional data flow from peripherals to PC. Additional usability features include, zero delay switching between connected sources and flexible assignment of audio devices.

The Cybex SC920XD KVM switch delivers strong, effective security management designed to tightly control system and network access and deliver transparent security that does not impede user productivity

  • Outstanding security - Designed to meet the requirements of the latest National Information Assurance Partnership (NIAP) Protection Profile V3.0 for peripheral-sharing devices.
  • Discrete processing paths - Isolated ports on the switch provide discrete processing paths to each system, preventing data leakage, transfer or crosstalk between adjacent ports.
  • Unique NUM Lock, CAPS Lock and Scroll Lock indicators - While the Cybex series maintains unidirectional data flow, it also provides indicators that alert users when the NUM Lock, CAPS Lock or Scroll Lock is on to improve ease of use.
  • Gain true image reproduction and display flexibility - Cybex KVM switches offer the industry's broadest range of video connections. The SC920XD supports HDMI 1.4, which delivers resolutions up to UHD 4K (3840X2160 @ 30 ).

Avocent SC920XD-001 Specifications:

Mechanical
Height 2.2 in (56 mm)
Width 7 in (178 mm)
Depth2.4 in (61 mm)
Weight1.5 lbs (0.7 kg)
MicrophoneNo
SpeakerYes
VideoDual-head HDMI 1.4 to DVI-I (dual-link/single-link) + DisplayPort 1.2
MAX ResolutionUHD 4K resolutions up to 3840x2160 @ 30 Hz (DisplayPort)
2560X1600 pixels @ 60 Hz (DVI)
Environmental
Operating Temperature32° to 104°F (0° to 40°C)
Storage Temperature-4° to 122°F (-20° to 50°C)
Humidity0-80% RH, non-condensing
Power
Operating Voltage100 to 240VAC
Power Consumption (max)12V DC 1.5A Power Adapter
Device Support
CertificationsRCM, EU, FCC Class B, VCCI, c-UL
CAC/DPPNo
Warranty3 Years

Avocent Cybex (by Vertiv) SC920XD is also known as SC 920XD

Question: Does this model have support for keyboard and mouse along with audio? Is there a picture with ports?
Answer: Thank you for your inquiry,

The Avocent (by Vertiv) SC920XD does indeed support Keyboard & Mouse along with Audio. While there isn't a picture available of the rear of the SC920XD HDMI to DVI & DP model, you can refer to the image below of the rear of the HDMI only model SC920H - Instead of having HDMI connections for all three sections of rear of the KVM (Local user section, and 2 sources sections), the SC920XD has HDMI on the user console section (left) and DVI and DP ports on the port sections (middle and right section):
SC920H back view
Please let us know if there is anything else we can help you with!
