4-Port 2K DisplayPort KVM Switch w/ Audio, Cables and USB 3.0 Hub
B004-DPUA4-K
Save $218.14
Control 4 DisplayPort computers using one DisplayPort monitor, USB keyboard and USB mouse with Tripplite B004-DPUA4-K. Connect USB 3.0 peripherals, such as hard drives and webcams, and share them between computers.
- Connect peripherals to built-in 2-port USB 3.0 hub
- Switch among computers via front buttons or keyboard hotkeys
- Supports digital video resolutions up to 2560 x 1600
- Supports USB 3.0 data transfer rates up to 5 Gbps
- Includes all necessary DisplayPort, USB 3.0 and audio cables
- Compatible with all major operating systems
Access and Control Up to 4 Computers with One KVM Switch
- Switch among computers using keyboard hotkeys or front-panel buttons
- Built-in DDC emulator sends console monitor's EDID (Extended Display Identification Data) to connected computers for top video quality without delay
- Auto Scan feature cycles among computers at regular intervals for at-a-glance observation of activity
Independent Audio Switching
- 3.5 mm mini-stereo speaker and microphone jacks allow sharing of audio equipment among computers
- Listen to audio files on one computer while accessing another computer
- Supports 2-channel stereo audio
Independent USB 3.0 Peripheral Sharing
- 2-port USB 3.0 SuperSpeed hub allows connection of peripherals, such as webcams, flash drives, printers and scanners
- Print documents from one computer while accessing another computer
- Supports USB 3.0 data transfer rates up to 5 Gbps
- Backward compatible with USB 2.0 and USB 1.1 devices
Compatible with All Major Operating Systems
- Easy to set up with no software or drivers to install
- Supports digital video resolutions up to 2560 x 1600, including 1080p
- Works with Windows, Mac, Linux and Sun
- All necessary cables included
Tripplite B004-DPUA4-K Specifications
General | |
Device Type | KVM / audio / USB switch - 4 ports |
Enclosure Type | Desktop |
Ports | 4 x KVM / audio / USB |
KVM Local Users Qty | 1 local user |
Keyboard / Mouse Interface | USB |
Max Resolution | 2560 x 1600 |
Expansion / Connectivity Interfaces | 4 x DisplayPort input x keyboard (USB) - Type A 4 x USB 3.0 - Type B 1 x DisplayPort output 1 x mouse (USB) - Type A 4 x microphone output - mini-jack 1 x microphone input - mini-jack 4 x headphones input - mini-jack 1 x headphones output - mini-jack 2 x USB 3.0 - Type A |
Power | Auto-sensing 100 to 240VAC, 50 / 60Hz |
Power Device | External power adapter (included) |
Voltage Required | AC 120/230 V ( 50/60 Hz ) |
Warranty | 1 Year Warranty - Sales & Support |
