SmartAVI Active DVI Repeater, Male to Female, 50ft

DVX-100S

$249.00$194.03
Save $54.97

Discontinued
Recommended replacement: Aten VE560
Alternative options: Contact Us

smartavi_madeinusa

The DVX100 extends the distance between any computer supporting DVI-D and monitors or projectors up to 50ft. The system features daisy chain capabilities that can extend the limit up to 100ft.

product

Applications

  • Presentations
  • Data Broadcasting
  • Learning and Training

Features

  • Supports MAC and PC DVI-D
  • Resolution up to 1920 x 1080
  • No loss of pixel
  • Maintains highest DVI single link video resolution
  • DVI output regenerates TMDS digital video
  • Output can drive long cable up to 50 feet unless daisy chained
  • Green led for power
  • External power supply
  • Provides noiseless operating environment at the remote station
  • Places CPU outside of harsh environment
  • Saves space on your desktop

diagram

SmartAVI DVX-PRX Specifications

Mechanical
Height 0.08 in. (.20 cm)
Width 2.75 in. (6.9 cm.)
Depth 3.4in. (8.6 cm.)
FormatDVI-D Single Link
aximum Pixel Clock165 MHz
ResolutionUp to 19020x1200 @60Hz
DDC5 volts p-p (TTL)
PowerExternal 5VDC 1A, 2A
Input Cable LengthUp to 20 ft
Output Cable LengthUpt to 20 ft
UPC / EAN Barcode icon
UPC 813280021104
EAN 0813280021104
