SmartAVI Point to Point Multimode USB KVM Fiber Extender



Recommended replacement: SmartAVI FDX-3000S
Alternative options: Contact Us

The SmartAVI DVX3000 extends the distance between any computer supporting DVI-D and monitors or projectors up to 1200ft. with fiber optics.  The DVX3000 consists of a Transmitter unit and a Receiver unit. These two devices enable long-distance, loss less transmission of DVI video signals between a digital video source and a digital display device. The DVX3000 is equipped with DVI-digital (Digital Visual Interface) connectors for a single-link and optional USB 1.1. The DVX3000 receiver is small enough to be attached near a projector. With the DVX3000, the maximum distance between the source and digital display is 330 feet (100 m) using CAT5 and up to 1200ft using fiber optic.

SmartAVI DVI Cat5 Extender Diagram
SmartAVI DVI Cat5 Extender Diagram

SmartAVI DVX3000 Features:

  • Perfect Image Quality at all Resolutions
  • Supports both VGA and the latest DVI video interfaces (future proof your investment)
  • Supports Mixed DVI and VGA operation
  • Video Resolutions up to 1600 x 1200 @ 60Hz using CAT5 or Fiber Optic Cable
  • Local Console Option (Dual Access)
  • Transparent to USB 1.1
  • No length restrictions for particular video resolutions
  • Fiber Optic Extension uses only TWO Fibers
  • Transmission length:
    • 100 m with regular CAT5 cable
    • (200 m with repeater)
    • 200 m with 62,5/125 Multi-mode Fiber Cable
    • 400 m with 50/125 Multi-mode Fiber Cable
    • 10 km with 9/125 Single-mode Fiber Cable
  • Compatible with all operating systems
  • Compatible with all major KVM Switches

SmartAVI DVX3000 Specifications:

Height 1.7 in. (43 mm.)
Width 5.8 in. (148 mm.)
Depth 6.7 in. (170 mm.)
Power Universal Switchmode PSU (90-240V Input)
Resolution 1600 x 1200 @ 60 Hz
All lower resolutions operate up to 75 Hz vertical refresh
Video Interface SXGA, SUN, DVI
Keyboard/Mouse Options PS/2 Microsoft Compatible
Interconnection Options Multi-mode 50/125e oder 62, 5/125e, SC-connector
Single-mode 9/125e, SC-connector, Cat5/5e/6
Maximum Distances 100 m (200 m) Cat5, 200 m (62, 5e), 400 m (50e), 10km (9e)
Upgradeable Onboard Flash
KVM Access Single/Dual KVM options
