True 4K DisplayPort 1.2-compliant fiber optic extender - 660 feet

EXT-DP-4K600-1SC

$3,109.05$2,169.10
Save $939.95
FREE Shipping on orders over $100

Gefen's EXT-DP-4K600-1SC DisplayPort 1.2-compliant fiber optic extender is a compact and high performance solution for extending HDCP 2.2, HDCP 1.4, and DPCP compliant DisplayPort 600 MHz 4K audio/video over fiber. . The AV signal can be extended up to 200m (660ft), over a single strand of SC-terminated 50/125 µm OM3 or better multi-mode fiber-optic cable. There is full electrical isolation between the Transmitter and the Receiver, meeting the stringent safety and EMC requirements for critical applications. When used with the Gefen EXTPS52AU-M-1.3-6-AL power supply (available separately), this extender is compliant with medical safety and EMC standards EN 60601-1 and EN 60601-1-2. The EXT-DP-4K600-1SC can be powered from sources and displays featuring powered USB ports, or by using external power supplies.

For most applications, the Transmitter and Receiver are plug-and-play and will work without any set-up. In cases where signal optimization becomes necessary due to special requirements of a source and/or a display, both units feature easy-to-use EQ switches. The EXT-DP-4K600- 1SC supports popular and useful DisplayPort technologies such as Multi-streaming (connecting multiple daisy-chained displays to one DisplayPort output) and Auxiliary Channel (transporting data and controls along with the AV signal).

Compact enclosures are easy to install and can be hidden away. Their sturdy metal enclosures help provide further immunity against ElectroMagnetic Interference (EMI) and radiated noise (RFI). Applications include medical imaging, military and industrial command and control rooms, flight simulators, digital signage, gaming, and wherever 4K full-bandwidth uncompressed video or end-to-end electrical isolation are essential.

Gefen EXT-DP-4K600-1SC Diagram

EXT-DP-4K600-1SC Features & Benefits

Gefen EXT-DP-4K600-1SC Product Banner

  • Supports Full-Bandwidth 4K 60 Hz 4:4:4 (600 MHz)
  • Fully compliant with DisplayPort 1.2 standard
  • Supports WQUXGA (4K; 3840x2400), 4K Ultra HD (3840 x 2160), and 4K Cinema - DCI (4096 x 2160) at 60Hz, 4:4:4
  • Extension up to 200m (660 feet) over one (1) SC-terminated multi-mode OM3 or better (50/125um) optic cable
  • HDCP 2.2, HDCP 1.4, and DPCP compliant
  • Supports DisplayPort Auxiliary/l_C channel
  • Supports DisplayPort Multi-stream technology
  • Compact enclosures are easy to install and can be hidden away.
  • Sturdy metal construction of the enclosures help provide further immunity against Electro-Magnetic Interference (EMI) and radiated noise (RFI).
  • Plug & Play - no configuration or set-up required for most applications
  • EQ switches on Transmitter & Receiver ensure compatibility with most sources & displays
  • Medical Safety (EN 60601-1) & EMC Compliant (EN 60601-1-2) when used with two EXT-PS52AU-M-1.3-6-AL power supplies (available separately)
  • Includes 2-year product warranty

EXT-DP-4K600-1SC Package Contents

  • 1 x EXT-DP-4K600-1SC-TX - Transmitter unit
  • 1 x EXT-DP-4K600-1SC-RX - Receiver unit
  • 2 x DisplayPort Male-to-Male cables, 6 feet
  • 2 x USB-to-DC cables, 2.3 feet
  • 2 x EXT-PS52AIP-1.3-6-AL power supplies and 2 sets of US AC Plugs
  • 1 x Quick-Start Guide

Gefen EXT-DP-4K600-1SC Specifications

Gefen EXT-DP-4K600-1SC Brochure (PDF)
Gefen EXT-DP-4K600-1SC Manual (PDF)

Mechanical
Dimensions (Transmitter/Receiver, not including connectors)1-3/4"W x 7/8"H x 3-1/8"D (45mm x 22mm x 79mm)
Net Weight (Transmitter/Receiver)4.8 oz. (0.135 kg) each
Shipping Dimensions (Set)7.6"W x 2.6"H x 14"D (45mm x 22mm x 79mm)
Shipping Weight2.5 lbs. (1.2 kg)
Video/Audio
Video Bandwidth21.6 Gbps (5.4 Gbps per lane, 4 lanes)
Max Pixel Clock600 MHz
Video In (Transmitter)1 x DisplayPort 1.2 (DP-20-pin, female)
Video Out (Receiver)1 x DisplayPort 1.2 (DP-20-pin, female)
Link Connectors
Link connector (Transmitter/Receiver)1 x Type SC
Link Indicator (Transmitter/Receiver)1 x LED, green
Power
ConnectorDC 3.5mm/1.3mm barrel jack
Supply5V DC
ConsumptionTransmitter: 1.75 Watts
Receiver: 2.0 Watts
Optical Power Budget6.5 dB
Environmental
Operating Temperature32°F - 122°F (0-50°C)
Storage Temperature-4°F - 158°F (-20-70°C)
Humidity10-85% RH, Non-condensing
MTBFTBD
