Gefen USB 100 USB KVM Extender



Recommended replacement: Gefen EXT-USB2.0-LR
USB 2.0 Cat5 Extender

Alternative options: Contact Us

The USB•100 extends any USB device, including a keyboard/mouse connection, up to 330 feet from the computer, eliminating the 17.5 feet distance limitation of USB. Both the USB•100 sender and receiver units use "Extreme USB" technology by Icron Systems Inc.

How it Works
The USB•100 sender unit is connected to the computer with a supplied USB cable. The receiver unit is connected to the extended peripheral. A CAT-5 cable links the sender to the receiver.

Gefen USB 100


  • Extends any USB device up to 330 feet away from computer
  • CAT-5 cable used for extension
  • Saves space on your desktop
  • Increases productivity
  • Plug and play - installs in minutes
  • For any computers with USB connection
  • Extends any USB hub with multiple USB outputs
  • No power supply required at the receiving end
  • Supports full 12.5 Mbs USB standard bandwidth


  • USB Speed: 12.5 Mbs
  • Link Connector: RJ-45
  • Host cable (USB): Type A/B
  • USB Connectors: 4Pin USB type A
  • Power Supply: External 15 VADC
  • Dimensions: 4.75"W x 1.75" H x 5"D
  • Shipping Weight: 5 lbs

Package Includes:

  • USB•100S Send Unit
  • USB•100R Receive Unit
  • One 6ft A to B USB cable
  • One 15v Power Supply
