Belkin Secure 4-Port Dual-Head DVI Windowing KVM

F1DN204M

$3,642.81
FREE Shipping on orders over $100

Regular secure KVM switches allow users to work on only one channel/computer at a time. The Belkin Secure Windowing KVM is the only product in the market today that was designed for environments in which the user needs to constantly work and monitor multiple channels, with different security levels, simultaneously. Regular secure KVM switches allow users to work on only one channel/computer at a time. The Belkin Secure Windowing KVM is the only product in the market today that was designed for environments in which the user needs to constantly work and monitor multiple channels, with different security levels, simultaneously. The Belkin Secure Windowing KVM offers superior security for government and high security agencies by providing true data path isolation between systems and networks. Fully compatible with legacy (using Belkin smart cables) and new government systems, and Common Criteria validated to EAL 4+ to assure the highest level of protection, the Belkin Secure Windowing KVM is the ultimate security and data protection solution for organizations that are required to interact simultaneously with multiple networks; including analysts and operators in defense and intelligence, or complex command and control environments.

Belkin F1DN204M Features:

  • View up to four networks simultaneously through a pixel-by-pixel video image, with no quality loss, latency, reduced colors, dropped frames or artifacts, all in real time. Work constantly and monitor multiple channels; no switching of channels required.
  • The Belkin Secure Windowing KVM has an advanced scaling function allowing the user to scale the video source x 1/2 and x 1/4 to assure a good view, and a superb working experience.
  • The Belkin Secure Windowing KVM offers users two additional, unique working modes: tile and scaling. The tile mode allows users to view all source windows in equal size scaled by 50%. The scale mode allows users to focus on one main source while viewing the other sources scaled by a 25%. These modes are a perfect solution for monitoring multiple sources simultaneously.
  • The dual display model of the Belkin Secure Windowing KVM supports two DVI displays. The dual display model is the ideal setup for high-end users. When the dual display model is used in scale mode, the active channel will be displayed on the main display, while the other three channels will be scaled by 50% and displayed on the secondary display.
  • A host of security features including - Unidirectional Data Paths, Dedicated Processors for Emulation, No Shared Resources and USB Port Protection making the Belkin Secure Windowing KVM the ultimate security solution for government agencies and private sector corporations with multiple security classifications.
  • The Belkin Secure Windowing KVM is Common Criteria validated to EAL 4+ (Evaluation Assurance Level 4) to assure the highest level of protection, and the product complies with Common Criteria, Protection Profile 2.1.

Belkin F1DN104E Backend

Belkin F1DN204M Specifications:

Mechanical
Height 1.3 in
Width 3.1 in
Depth 6.2 in
Weight 2.2 lbs
Environmental
Operating Temperature 32-104 F
Storage Temperature

-4-140 F

Humidity

0-80% Non-condensing

Power
Power Device External power adapter
Voltage Required AC 120/230 V (50/60 Hz)
Expansion / Connectivity Interfaces: 8 x DVI-D output, 4 x keyboard (USB) / mouse (USB) - Type B, 1 x keyboard (PS/2), 1 x mouse (PS/2), 4 x audio output - mini-jack, 3 x USB - Type A, 4 x USB - Type B, 1 x audio input - mini-jack, 2 x DVI-D input
General
Device Type KVM / audio switch - 4 ports
Enclosure Type Desktop
Ports 4 x KVM / audio
Max Resolution 1920 x 1200
Features Common Access Card (CAC) reader support
Status Indicators Port status
Standards
Approved Agency EAL4+
Warranty 3 years
