SmartAVI HDMI, IR, and RS-232 CAT5 Extender (TRANSMITTER ONLY)



For upgrade or replacement options: Contact Us

The SmartAVI HDXU-TXS is a HDMI, IR, and RS-232 CAT5 Transmitter. It Includes: HDXU-TX (Transmitter), SM-LED3 and PS5VD2A-1(Power Supply).

SmartAVI HDXU-TXS Features:

  • Extends HDMI output over one Cat5/5e/6 UTP cable
  • Extends IR and RS-232 control signals for remote control
  • Delivers uncompressed HD video up to 1080p @ 60Hz @ 48 bits and 3D
  • Data signals up to 3.4 Gbps
  • HDMI 1.3 and HDCP compliance
  • IR and RS-232 communication are bi-directional
  • Transmits high quality Dolby TrueHD, DTS-HD MA audio signals
  • Transmits 1080p resolution over 330 feet (100 meters) from the source

SmartAVI HDXU-TXS Applications:

  • Home Theater
  • Corporate Presentations
  • Educational Presentations
  • Call Centers
  • Industrial Long-Range Workstation Isolation
  • Information Terminals/Kiosks
  • Airport Installations

SmartAVI HDXU-TXS Application Diagram

SmartAVI HDXU-TXS Application Diagram

 SmartAVI HDXU-TXS Specifications:

Width 5.0 in. (12.7 cm.)
Height 1.125 in. (2.85 cm.)
Depth 4.125 in. (10.47 cm.)
Weight 0.6 lb. (0.27 kg.)
Format HDMI 1.3 and HDCP compliant
HDTV Resolutions 480p, 720p, 1080i, 1080p/60Hz/48bit
TV Resolutions 480i
Input Interface (TX) HDMI Type A 19-pin Female TMDS
Output Interface (RX) HDMI Type A 19-pin Female TMDS
Input Cable Length (TX) Up to 40ft.
Output Cable Length (RX) Up to 40ft.
Format Dolby TrueHD, DTS-HD MA
Input Interface HDMI (Integrated)>/td>
Output Interface HDMI (Integrated)
Signal Type 38 KHz
Interface 3.5mm Jack Socket (Female)
Baud Rate Up to 19,200 bps
Input Interface (TX) DB-9 (Serial) Female
Output Interface (RX) DB-9 (Serial) Male
Interface RJ-45
Cable Requirements Cat5/5e/6
Maximum Length 330 (100 meters)
Power External 100-240 VAC/5VDC2A @ 10W
Operating Temperature 0-55 °C (32-131°F)
Storage Temperature -20-85 °C (-4-185 °F)
Humidity Up to 95%
Approvals UL, CE, ROHS Compliant

*Please note that this specification detail also lists the details concerning the receiver.
