IR Matrix Router up to 32x32

IRB-MXU-32PS

$999.00

Discontinued
For upgrade or replacement options: Contact Us

For long-distance control of a matrix and a matrix's input sources, the IR-Blaster provides users with the ultimate in flexibility. Often, when using a matrix or other switch, users have difficulty when needing to switch input and output sources while also controlling the devices that deliver signal to the matrix. The IR-Blaster provides a unique and simple solution to handle all those functions from a more convenient location by utilizing infrared signals and the data transferring capabilities of HDMI cables. The IR-Blaster features full matrix signal routing so that each IR input can be routed to any combination of IR outputs. Additionally, each output can drive the IR emitter up to 30 feet away. The router is fully compliant with standard modulated IR protocols and the latest IRDA standards

Applications for the IRB-MXU-32PS include:

  • Wall Displays
  • Digital Signage
  • Airports
  • Dealer Rooms
  • Control Rooms
  • Audio/Visual Presentations
  • Shopping Centers
  • Security
  • Hotels/Resorts

SmartAVI IRB-MXU-32PS Features:

  • Controls routers up to 32x32
  • Full matrix signal routing - each IR input can routed to any combination of IR outputs
  • Fully compliant with standard modulated IR protocols and the latest IRDA standards
  • Enables matrix switching and input device control
  • Allows users to control A/V set ups remotely
  • Features SmartAVI SRC-2A remote control

SmartAVI IRB-MXU-32PS
SmartAVI IRB-MXU-32PS Diagram

SmartAVI IRB-MXU-32PS Specifications:

IR Eye Input
IR Frequency Range30KHz to 80KHz
Capture DistanceUp to 30'
Cable Connector3.5mm mono jack
IR Signal IndicatorGreen LED
Signal TypeTTl
IR Emitter Output
IR Frequency Range30KHz to 80KHz
Capture DistanceUp to 25'
Cable Connector3.5mm stereo jack
IR Signal IndicatorGreen LED
Other
Power Requirements12VDC 2A
Dimensions17W x 3.75H x 1.75D in
Weight5Lbs. (2.43Kg)
Cable LinkDb25 to matrixes
UPC / EAN Barcode icon
UPC 813280022064
EAN 0813280022064
