Aten 8 Port 19 in. Dual Rail CAT5 LCD KVM w/ 8 USB CPU dongles

KL1508AMUKIT

$2,550.00$2,000.12
Save $549.88
FREE Shipping on orders over $100

The Aten KL1508AMUKIT is an 8 Port 19 in. Dual Rail Cat5 LCD KVM with 8 USB CPU Dongles.

Aten KL1508AMUKIT Features:

  • KVM console with 19" LCD monitor in a sliding housing with top and bottom clearance for smooth operation in a 1U high rack
  • RJ-45 connectors and Cat 5 cable - extends the distance between computers and switch up to 40m (130') for resolutions of 1280 x 1024 @60Hz
  • Dual Rail operation - LCD monitor slides independently of the keyboard/ touchpad
  • A dedicated console port for management from an external console - plus an extra PS/2 mouse port for external mouse use with the integrated LCD console
  • KVM adapter cables with automatic conversion allow flexible interface combinations. PCs, Macs, Sun computers, and serial devices can all coexist on the installation
  • A single console controls up to 8 directly connected computers - daisy chain up to 31 additional units to control up to 256 computers
  • No software required - convenient computer selection via port selection switches, Hotkeys and intuitive On Screen Display (OSD) menus
  • Console lock enables the sliding console to remain securely locked away when not in use
  • OSD screen automatically adjusts to resolution changes - OSD tree structure makes finding and managing computers easy
  • Quickly and conveniently switch to any computer with station and port selection switches LED displays indicate the station and port location
  • Video settings of attached computers are automatically adjusted for optimal output to the LCD monitor
  • Auto Scan feature for monitoring user-selected computers
  • Two level password security - only authorized users view and control the computers - up to four users plus an administrator with separate profiles for each
  • Broadcast support - commands from the keyboard can be broadcast to all available computers on the installation
  • Dedicated keys to invoke Hotkey Mode and the OSD from the keyboard for quick access to these functions
  • Rack mountable in 19" System Rack (1U) - standard rack mount kit included - optional Easy Rack Mount (single person installation) kit available (requires separate purchase)


Package Includes:

  • 1 x KL1508N
  • 8 x KA9570


Aten KH1508NUKIT Application Diagram
Aten KL1508AMUKIT Application Diagram


Aten KL1508AMUKIT Specifications:

Mechanical
Width 36 in. (91.4 cm.)
Height 12 in. (30.5 cm.)
Depth 36 in. (91.4 cm.)
Weight 38.2 lbs. (17.4 kgs.)
Housing Metal
UPC / EAN Barcode icon
UPC 881317509284
EAN 0881317509284
