1U 4K 17" Rackmount KVM Drawer with 4-Port HDMI USB KVM Switch

RACKMUX-4K17-N-4HD4K

$2,295.00$2,110.34
Save $184.66
KVM Switch Ports: 4
FREE Shipping on orders over $100

The RACKMUX-4K17-N-4HD4K is a 4K KVM Drawer with Built-In 4-Port 4K HDMI USB KVM Switch combines a rackmount 4Kx2K LCD monitor, keyboard, touchpad mouse and a 4K HDMI USB KVM Switch in a space-saving 1RU industrial strength drawer. Control up to four Ultra-HD 4Kx2K 30Hz HDMI USB computers from one user station!

  • Forward-folding 17.3" TFT/LCD monitor.
  • Supports Ultra-HD 4Kx2K resolutions (3840x2160@30Hz).
  • Integrated 4-port 4K HDMI USB KVM Switch in 1U
    • Control up to 4 Ultra-HD 4Kx2K 30Hz USB computers.
  • Torque-friction hinges - monitor does not wobble, spring, or slam shut.
  • Compact, heavy-duty tactile keyboard with 17-key numeric keypad.
  • Rugged steel construction with durable powder coat finish.
  • LCD auto-shutoff in closed position.
  • Drawer locks into place when open to prevent it from sliding in and out of the rack
  • Designed to be a one-person job when installing the drawer.
NTI RACKMUX-4K17-N-4HD4K Back Rear View

RACKMUX-4K17-N-4HD4K Package Contents

NTI RACKMUX-4K17-N-4HD4K Package Contents

  • (1) NTI RACKMUX-4K17 KVM Drawer with integrated UNIMUX-HD4K-4 KVM switch
  • (1) 1U 19" Rack Mount Kit - Single-Person Installation
  • (1) US Power Cord
  • (1) DB9 Female-to-RJ45 Female adapter
  • (1) 5 foot RJ45-to-RJ45 CAT5 patch cable
  • (1) Manual Card
  • (1) 2-Year Standard Warranty

RACKMUX-4K17-N-4HD4K Resources

NTI RACKMUX-4K17-N-4HD4K Manual NTI RACKMUX-4K17-N-4HD4K Brochure (PDF)
NTI RACKMUX-4K17-N-4HD4K Manual (PDF)

NTI RACKMUX-4K17-N-4HD4K Specifications

Dimensions (H x W x D)
  • 1.75 x 7.35 x 4.98 in. (45 x 187 x 126 mm)
Monitor
  • Supports Ultra-HD 4Kx2K resolutions to 3840x2160 (30Hz), 2K resolution 2048x1080 (60Hz), and HDTV resolutions to 1080p (60Hz).
  • One female HDMI-A connector.
  • Compliant with HDMI 1.4 and HDCP 1.4 standards.
Devices
  • Two transparent female USB 2.0 Type A connectors for additional USB devices.
    • Supports high-speed (480 Mbps), full-speed (12 Mbps) and low-speed (1.5 Mbps) USB devices including, but not limited to, touchscreens monitors, CAC card readers, printers, scanners, and thumb drives.
Power110 or 220 VAC at 50 or 60 Hz via IEC connector.
Environmental
  • Operating temperature: 32F to 104F (0°C to 40°C).
  • Storage temperature: -4°F to 140°F (-20°C to 60°C).
  • Operating and storage relative humidity: 20 to 90% non-condensing RH.
Regulatory Approval
  • CE, RoHS
  • TAA compliant
Warranty2-Years
