High Definition Low-Bandwidth Encoder
SAVI-ST-E300S
Save $286.79
The SaviStreamer E300 Encoder is SmartAVI's ideal streaming optimization hardware solution. The SaviStreamer digitizes audio and video signals from connected devices, optimizing them for web-based streaming distribution with low-bandwidth, high speed H.264 formatting. Connectable via HDMI, VGA, and analog ports, the SaviStreamer supports a wide array of media file types and sizes and preps them for web transmission without loss in picture quality or performance.
Built with excellent encoding fail-safes and highly compatible designs for system stacking, the SaviStreamer E300 is the ideal device for any AV specialists who need media content on the web.
Product Benefits and Features
- HD H.264 video (1080p at 60fps)
- AV-over-IP support
- Low-Bandwidth, Energy Efficient
- HDMI, VGA, Analog Ports
- Supports wide array of media sizes and types
- Schedule and record live HD content
- Robust Encoding Fail-safes
- Shared network recording
- Stackable, powerful systems
| Mechanical | |
| Width | 17.2 in (436.9 mm.) |
| Height | 8.30 in. (211 mm.) |
| Depth | 1.75 in. (44.5 mm.) |
| Weight | 6.17 lbs. (2.8 kgs.) |
| Video | |
| Format | HDMI 1.4 |
| DVI Compliance | Single-link DVI-D 1.1 w/ Adapter |
| HDCP Compliance | 1.0/1.1 |
| Video Bandwidth | Single-link 340MHz (10.2Gbps) |
| Resolution | Up to 3840x2160 @30Hz |
| Input Interface | (1) HDMI [7.1ch audio & video], (1) VGA |
| Output Interface | (1) HDMI [7.1ch audio & video] |
| Connector | HDMI Type-A (19-pin female), VGA, USB Type-B (female), RS-232, LAN, Stereo Audio (3.5mm jack socket) |
| Max Cable Length | 20 ft. |
| Controls | |
| Front Panel | Tact Switch |
| PC | RS-232 Control |
| IR | Via Remote Control with IR Type 3 |
| TCP/IP | via Web Browser |
| Other | |
| Operating Temperatures | 32-95°F (0-35°C) |
| Humidity | 0-95% Non-Condensing |
| Power | External 100-240 VAC/12VDC4A |
| Consumption | 20W |
UPC 813280023115
EAN 0813280023115
