2-port Secure EAL4+ KVM, Dual Monitor DVI-I (dual-link), Audio
SC920-001
Save $337.65
End-Of-Life (EOL)
For stock: Contact Us
Replaced by: Vertiv SC920DPH-400
Vertiv Cybex SC920 Brochure (PDF)
Vertiv Cybex SC920 Manual (PDF)
The Avocent Cybex SC920 secure desktop KVM is designed to meet the stringent specifications of the U.S. government and comply with the requirements of the latest NAIP protection profile for peripheral sharing devices version 3.0. The SC920 delivers proven security features such as unidirectional data diode technology, which assures complete network isolation while offering user-friendly, easy switching between sources. An active anti-tampering system and holographic tampering evident labels alert the user when the system has been physically compromised. Patented emulation technology prevents Display Data Channel (DDC) signal leakage; and guards against signal attacks.
Industry-leading security features are complemented with a range of capabilities and productivity features that make the Cybex SC920 a great investment. Experience true image reproduction with support for dual-link DVI-I, which delivers resolutions up to UHD 4K (3840X2160 @ 30 ), via DVI to HDMI cable. NUM Lock, CAPS Lock and Scroll Lock indicators improve user interaction while maintaining unidirectional data flow from peripherals to PC. Additional usability features include, zero delay switching between connected sources and flexible assignment of audio devices.
The Cybex SC920 KVM switch delivers strong, effective security management designed to tightly control system and network access and deliver transparent security that does not impede user productivity
- Outstanding security - Designed to meet the requirements of the latest National Information Assurance Partnership (NIAP) Protection Profile V3.0 for peripheral-sharing devices.
- Discrete processing paths - Isolated ports on the switch provide discrete processing paths to each system, preventing data leakage, transfer or crosstalk between adjacent ports.
- Unique NUM Lock, CAPS Lock and Scroll Lock indicators - While the Cybex series maintains unidirectional data flow, it also provides indicators that alert users when the NUM Lock, CAPS Lock or Scroll Lock is on to improve ease of use.
- Gain true image reproduction and display flexibility - Cybex KVM switches offer the industry's broadest range of video connections. The SC920 supports dual-link DVI-I, which delivers resolutions up to UHD 4K (3840X2160 @ 30), via DVI to HDMI cable.
*** PLEASE NOTE: For DVI-D video cards please use Vertiv DVI-D only cables. For VGA video cards please use VAD-28 with Vertiv DVI-I cables
*4-Port SC940 KVM Back View
Avocent SC920-001 Specifications:
| Mechanical | |
| Height | 2.2 in (56 mm) |
| Width | 7 in (178 mm) |
| Depth | 2.4 in (61 mm) |
| Weight | 1.5 lbs (0.7 kg) |
| Microphone | No |
| Speaker | Yes |
| Video | 2 x Dual-monitor DVI-I, single-link/dual-link HDMI and VGA with adapter |
| MAX Resolution | UHD 4K - 3840x2160 pixels @ 30 Hz (via DVI to HDMI cable) DVI dual-link - 2560x1600 pixels @ 60 Hz (via DVI cable) VGA - 2048x1536 pixels |
| Environmental | |
| Operating Temperature | 32° to 104°F (0° to 40°C) |
| Storage Temperature | -4° to 122°F (-20° to 50°C) |
| Humidity | 0-80% RH, non-condensing |
| Power | |
| Operating Voltage | 100 to 240VAC |
| Power Consumption (max) | 12V DC 1.5A Power Adapter |
| Device Support | |
| Computers | USB and single-head DVI-I |
| Certifications | RCM, EU, FCC Class B, VCCI, c-UL |
| CAC/DPP | No |
| Warranty | 3 Years |
Avocent Cybex (by Vertiv) SC920 is also known as SC 920
