5.1 Channel Digital-to-Analog Audio Converter with USB Video

SMA-U200S

The SMA-U200 enables users to convert two digital audio signals to RCA audio, with support for impressive surround sound and a variety of EQ presets. The device helps make the latest in digital content sources like DVD players compatible with wide variety of audio equipment. The device also supports playback from a USB input, including music, video, photo and text files. Users can change the input source using the tact switch on the device, or with the included remote control. There's no need to buy all new, expensive digital equipment to get the most out of the latest content, the SMA-U200 makes compatibility a non-issue.

Product Features and Benefits

  • Switch between two digital audio inputs and one USB2.0 input
  • Uses 24 bit/96KHz audio DSP and 24bit /192KHz DAC
  • Supports for multiple EQ settings
  • Supports Dolby Digital (AC3), DTS and LPCM audio
  • Supports music, video, photo and text files via USB
  • USB port provides charging for mobile devices
  • Automatic identification of input format
  • Supports stereo and 5.1 channel output modes
  • High tone quality, low noise
  • Support for remote operation, visual menu interface

Product Diagram

Mechanical
Width5.5 in (139.7 mm.)
Height0.85 in. (21.59 mm.)
Depth2.5 in. (63.5 mm.)
Weight0.46 lbs (0.21 kg)
Specifications
Digital audio decode formatDolby Digital (AC3)/DTS/LPCM
USB playback music formatMP3 / WMA / AAC / WAV
USB playback video formatDivx3.11,4.x,5.x/Xvid/AVI/MJPEG/ VOB/VCD(Dat)/MPG1,2,4
USB playback photo formatJPG (Resolution range: 16x16~10000x10000)
DSP sample frequency range32~96 KHz
DSP Bit rate range16~24 Bit
Digital input level0.1~1Volts p-p
Analog output level(1kHz@0dB)1V RMS
SNR @ 0dB (CCIR/ARM)≥85dB
Distortion≤0.1%
Frequency response20Hz~20KHz
Power
Max working current400mA
Power adapter format InputAC 100V~240V 50HZ/60Hz, DC5V/1A
Environmental
Operating Temperature range14-131°F (-10-55°C)
Storage Temperature range-4-140°F (-20-60°C)
Operating Humidity range10-90% RH, Non-Condensing
Storage Humidity range5-95% RH, Non-Condensing
