The UNIMUX-HD4K-16 HDMI USB 16-Port KVM Switch allows a user to control up to 32 Ultra-HD 4Kx2K 30Hz USB computers with one USB keyboard, USB mouse and 4K HDMI monitor. Dedicated internal microprocessors emulate keyboard and mouse presence to each attached CPU 100% of the time so all computers boot error-free.
- Control 16 HDMI USB computers or devices from one user station
- Supports Ultra-HD 4Kx2K resolutions to 3840x2160 (30Hz), 2K resolution 2048x1080 (60Hz) and HDTV resolutions to 1080p (60Hz).
- Compatible with USB computers (PC, SUN and MAC).
- Switch sources through the front panel buttons, hot-key keyboard commands, OSD, or RS232.
- Two transparent USB 2.0 ports (low/full/high speed), in addition to keyboard and mouse ports, for connecting USB devices such as printers, game controllers, USB flash drives, touch screen monitors, whiteboards, etc.
- Features NTI's patented true autoboot USB switching - all attached computers can be booted simultaneously.
- High quality steel construction.
- Flash upgradeable.
- 1U 19" Rackmount kit included.
UNIMUX-HD4K-16 Package Contents
- (1) UNIMUX-HD4K-16 USB 4K Video KVM Switch
- (1) Rack mount kit
- (1) US Power Cord
- (1) DB9 Female-to-RJ45 Female adapter
- (1) 5 foot RJ45-to-RJ45 CAT5 patch cable
- (4) Rubber feet
- (1) 2-Year Standard Warranty
NTI UNIMUX-HD4K-16 Brochure (PDF)
NTI UNIMUX-HD4K-16 Manual (PDF)
UNIMUX-HD4K-16 Firmware (Link)
UNIMUX-HD4K-16 Control Program (Link)
NTI UNIMUX-HD4K-16 Specifications
