HDMI HDBaseT-Lite Transmitter (4K@40m) (HDBaseT Class B)
VE801T
Save $31.47
The VE801T HDMI HDBaseT-Lite Transmitter connects with HDBaseT receivers to extend signals up to 70m from the source using one Cat 5e/6/6a cable. It supports HDMI features that include 3D, Deep Color and 4K image resolutions, plus Dolby Digital 5.1, DTS HD audio and it is HDCP compatible. The VE801T all-in-one design provides an easy method for mounting the device in any location. The side panel provides slip-resistant grooves that help prevent accidental drops when installing the unit. The grooves also enhance the ability to see the LED status lights. The VE801T is perfect for digital entertainment centers or any installation that requires superior HDMI video quality to be extended at great distances.
Product Features
- HDBaseT Connectivity - extends an HDMI connection over a long distance via one Cat 5e/6/6a cable
- HDBaseT Anti-jamming - resists signal interference during high-quality video transmission using HDBaseT technology
- EDID Expert - configures optimum EDID settings for smooth power-up, high-quality display and use of the best resolution across different screens
- Rack- Mountable
Package Includes
- 1x VE801T HDMI HDBaseT-Lite Extender
- 1x Power Adapter
- 1x User Instructions
Product Specifications
| Video Input | |
| Interfaces | 1 x HDMI Type A Female |
| Impedance | 100Ω |
| Max Distance | 1.8 m |
| Video Output | |
| Interfaces | N/A |
| Impedance | N/A |
| Video | |
| Max Data Rate | 10.2 Gbps (3.4 Gbps Per Lane) |
| Max Pixel Clock | 340 MHz |
| Compliance | HDMI (3D, Deep Color, 4K); HDCP Compatible; Consumer Electronics Control (CEC) |
| Max Resolutions/Distance | Up to 4K@35m (Cat 5e/6) / 40m (Cat 6a); 1080p@60m (Cat 5e/6) / 70m (Cat 6a) *4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
| Audio | |
| Input | 1 x HDMI Type A Female |
| Output | N/A |
| Power | |
| Connectors | 1 x DC Jack with locking |
| Consumption | 5V DC, 1.85W |
| Environmental | |
| Operating Temperature | 32°-104°F (0°-40°C) |
| Storage Temperature | -4°-140°F (-20°-60°C) |
| Humidity | 0-80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 0.53 lb (0.24 kg) |
| Dimensions (L x W x H) | 4.91 x 3.43 x 1.18 in. (12.47 x 8.70 x 3.00 cm) |
UPC 672792006166
EAN 0672792006166
