USB K/M, Audio, VGA/DVI and RS-232 Extender, up to 1,400 ft.
FVX-3000S
The FVX-3000 consists of a transmitter and receiver that extend KVM, VGA, audio and RS-232 signals. It is a professional quality KVM capable of extending signals up to 1,400 feet over a single multimode fiber optic cable.
Product Features and Benefits
- Top Signal Quality at Maximum Extension
- Over Multimode Fiber (1,400 ft.)
- Superior Image Quality at all Resolutions
- Video Resolutions up to 1920 x 1200 at 60Hz (1280 x 1024 at 75Hz)
- Customizable/Programmable DDC Table
- Supports USB Keyboard/Mouse
- Supports Stereo Audio
| Mechanical | |
| Width | 5.5 in (139.7 mm.) |
| Height | 1.70 in. (43.18 mm.) |
| Depth | 4.5 in. (114.3 mm.) |
| Weight | 8 lbs (3.63 kg) |
| Video | |
| Input Interface | VGA Female (Single-Link) |
| Output Interface | DVI-I, VGA or DVI |
| Resolution | 1920x1200 at 60Hz |
| DDC | Internal Table can be Re-programmed |
| Audio | |
| Signal Type | Stereo Audio |
| Bandwidth | 15MHz, 0dB |
| Impedance | 10K Ohm |
| Connector | 3.5mm Stereo Mini Female |
| Other | |
| RS-232 | PS/2, MAC-ADB, SUN |
| USB | PS/2, Wheel Mouse |
| Fiber Extender | Fiber: 225m @ Multimode 62, 5µ; 450m @ Multimode |
UPC 813280021456
EAN 0813280021456
Question: Can you tell me the Fiber cable connector that is required to interface to the unit
Answer: Thank you for your inquiry,
The SmartAVI FVX-3000S uses a single multimode fiber optic cable with a 'LC' connector type.
The distance of the extension with the FVX-3000S would deped on the type of OM fiber cable ("optical mode" designation as outlined in the ISO/IEC 11801 standard):
Multimode OM1 cable (62.5 ì / Micron): 738 Ft (225 m)
multimode OM2, OM3, OM4 cable (50 ì / Micron): 1,476 Ft (450 m)
If you would like a recommendation based on your application, please feel free to contact your KVM Switches Online sales representative.
Answer: Thank you for your inquiry,
The SmartAVI FVX-3000S uses a single multimode fiber optic cable with a 'LC' connector type.
The distance of the extension with the FVX-3000S would deped on the type of OM fiber cable ("optical mode" designation as outlined in the ISO/IEC 11801 standard):
Multimode OM1 cable (62.5 ì / Micron): 738 Ft (225 m)
multimode OM2, OM3, OM4 cable (50 ì / Micron): 1,476 Ft (450 m)
If you would like a recommendation based on your application, please feel free to contact your KVM Switches Online sales representative.
