HDMI, LAN or CAT5e/6 Transmitter (transmitter only)

HLX-TX500S

$199.00$155.06
Save $43.94
FREE Shipping on orders over $100
smartavi_madeinusa

The HLX-500 HDMI Transmitter gives users the freedom to extend HDMI signals via LAN, using inexpensive Cat5e/6 cables that many modern communications already rely on. This chainable extender can be used to generate thousands of feet of HDMI signal extension, breaking distance barriers. Users can set up their own extension cabling or utilize the pre-existing LAN infrastructure they have access to. Each unit extends signals up to 500 feet. With no software or driver required, users can easily extend HDMI signals such as HDTV, Blu-Ray, video game consoles and more. HLX-500 supports 1080p HD video up to 1920x1080 resolution at 60Hz and is Infrared Remote enabled.

The HLX-500 compresses data to utilize Cat5e/6 cables, but users will see no degradation of signal when using one gigabit Internet connections and up. For users utilizing pre-existing LAN connections, implementing a one gigabit switch allows for full resolution extension. Users with smaller bandwidth will experience compressed signals, if they so choose.

Applications

  • Extends HDMI signal up to 500 feet via LAN (Cat5e/6 cables)
  • Chainable for thousands of feet of extension
  • Supports high resolution 1080p HD video, 1920x1080 at 60Hz
  • Supports stereo audio
  • IR (Infrared) remote enabled
  • Bracket mountable
  • No software or driver required
  • Plug-and-Play ready

Features

  • Extends HDMI signal up to 500 feet via LAN (Cat5e/6 cables)
  • Chainable for thousands of feet of extension
  • Supports high resolution 1080p HD video, 1920x1080 at 60Hz
  • Supports stereo audio
  • IR (Infrared) remote enabled
  • Bracket mountable
  • No software or driver required
  • Plug-and-Play ready

diagram

SmartAVI HLX-500 Transmitter Specifications

Mechanical
Height 1 in. (2.54 cm)
Width 4 in. (10.16 cm.)
Depth 4.35 in. (11.04 cm.)
FormatHDMI 1.3 and HDCP compliant
HDTV Resolutions480p,720p,1080i, 1080p, 60Hz/48bit
TV Resolution480i
Input Interface (TX)HDMI Type A 19-pin Female TMDS
Input Cable Length (TX)Up to 40 ft
Audio FormatDolby TrueHD, DTS-HD MA
Input/Output Interface HDMI
IR Signal Type38 KHz
IR Interface3.5 mm Jack socket
RS-232 Baud RateUp to 19,200 bps
RS-232 Input InterfaceDB-9 (Serial)Female
Power External 100-240 VAC/5VDC2A @10W
UPC / EAN Barcode icon
UPC 813280022019
EAN 0813280022019
