15" Rack Mount Keyboard Drawer w/ High Brightness LCD & 8-Port PS/2 KVM Switch



Recommended replacement: Raloy RF117HD
Alternative options: Contact Us

15" 1.5U Rackmount High Brightness LCD Monitor w/8 Port KVM (comes with 8 6' cables)

HRKP series is a combination of keyboard, mouse and high brightness monitor with KVM switch into a drawer, with features such as flip-up design, adjustable brackets, and built-in LCD OSD to provide effective assistance for an administrator to control multiple PCs.


HRKP series is cost effective for your limited IT budget over using CRT and rack mounting. Also, it is space saving for your compact environment rack.

AH HRKP115-801 Features

  • 1.5U 15" LCD screen
  • Rear rackmount bracket included.
  • Standard D-sub 15-pin VGA input connector.
  • Provides the longest lamp life possible for all brightness levels.
  • Power saving feature for prolonging the life of LCD panel
  • High brightness and contrast enhances display panel
  • Unique mechanical design to maximize rack mountable space.
  • Slide rails have fixed position to prevent movement of keyboard.
  • Lightweight aluminium construction - with a black anodize finish.
  • Built in On Screen Display controlled by integral membrane switches.
  • Brightness more than 1400cd/m2
  • Adjustable mounting brackets from 390mm to 790mm (front to rear 19" mounts)

AH HRKP115-801 Specifications

  Panel Samsung 15" LCD Panel
  Screen Type TFT
  Display Area 304.1(H) x 228.1(V) mm
  Contrast Ratio 300 : 1
  Viewing Angle 115 ° (H) x 100 ° (V) (Typ.)
  Resolution 1024 x 768
  Pixel pitch 0.297(H) x 0.297(W) mm
  Response Time Tr=5ms, Tf=20ms (Typ.)
  Brightness 1400 cd/m2
  Panel Color 16.7M
  Back Light 4 CCFTs
(Cold Cathode Fluorescent tube)
  Horizontal Synchronization 48 - 60 KHz (Typ.)
  Vertical Synchronization 60-75 Hz (Typ.)
  Input Signal Analog RGB 0.7Vp-p
  Power Management VESA DPMS
  OSD Control

Brightness, Contrast, Colour, Clock,
H.Position, V.Position, Phase, Scaling,
Auto config, Input select, Multi window,
Clear EEPROM, OSD adjust, Save
  External Connection
  Power Input 12V/5A DC adapter
  Video Input 15-pin D-Sub connector
  Product dimension 43.9(W) x 6.6(H) x 60(D)cm
  Packing dimension 73.5(L) x 57.5(W) x 18(H)cm
  Net / gross weight

27.55 lb / 43 lb
12kg / 21kg
