Rose Vista M-series 4-Port KVM Switch

KVM-4UPH-K

$249.00$217.88
Save $31.12
FREE Shipping on orders over $100

Rose Vista M-series 4-port KVM switch with DB25 connectors. Includes two 5' and two 10' cables.

Rose Vista M-series Switch Kit Features and Benefits

  • Low cost
  • Chassis size: 9" wide, rack mountable 4-port, optional Apple support
  • Two 5' cables included
  • Connectors available in two styles:
    • DB25 connectors, uses Rose UltraCable, supports USB
    • PC connectors, uses native connectors for keyboard, video, and mouse
  • Works with all PCs and most UNIX workstations
  • USB support on DB25 models (with UltraCables)
  • Supports wheel and serial mice
  • Select computer from front panel or from easy to use keyboard commands
  • Front panel LEDs show computer selected, power status, and activity
  • Powered by your computer, no external power supply required
  • Scan mode sequences through computers at adjustable rate
  • Non-volatile memory stores configuration settings
  • Rack mountable
  • Made in USA

The Rose Vista Advantage

The Rose Vista M-series models work well either at the desktop or in server racks. They can be rack mounted, and are 1U high. They have high resolution video and are available in PC and multi-platform versions. The multi-platform version supports the Apple ADB interface and is available in DB25 only. Each port is programmable as PC or Apple.

Keyboard and Mouse: All Vista models support full emulation of keyboard and mouse. It works with major operating systems such as Windows, Linux, and UNIX running on workstations such as SGI, IBM RS/6000, HP 9000, Dec Alpha, and others. All models support PS/2, PS/2 wheel, or serial mice. This model supports a physical serial mouse. When using the DB25 models with USB cables, you can use PC-USB, Apple-USB, or Sun-USB.

Video: All Vista models have very high resolution capability and support VGA video beyond 1600 x 1280 non-interlaced. Keyboard, mouse, and video signals can be driven up to 1000 feet using our CrystalView extenders.

Rose Vista M-series Switch Kit Specifications
Dimensons/Weight

  8.8" W x 3.4" D x 1.75" H / 2 lbs (1U)
22.4 W x 8.6 D x 4.4 H (cm) / .9 kg
Input Power Supply   Supplied by computers; optional power available
Video Resolution   1920 x 1440
Connectors




  Video: HD 15 Female VGA Video
Keyboard: MiniDin-6F
Mouse: MiniDin-6F
CPU PC models: HD15F/MiniDin-6F/MiniDin-6F
DB25 models: DB25 Female
Rack mount   19", 23", or 24"
Chassis

  Fully shielded, black painted steel with polyester graphic overlay panel
Controls

  Computer Select Switch: 1-8 (varies by model)
Status LED, shows keyboard-mouse activity
Indicators

  Computer select LEDs 1-8 (varies by model)
Computer power LEDs 1-8 (varies by model)
Environmental   0°- 55°C, 0%-80% non-condensing relative humidity
Approvals   CE
