Rose Vista T-series 2-Port KVM Switch


Save $15.28
FREE Shipping on orders over $100

Rose Vista T-Series 2-port KVM switch with DB25 connectors. Includes two 5' cables.

Rose Vista T-Series Switch Kit Features and Benefits

  • Low cost
  • Chassis size (mini): Pocket-size 2-port
  • Two 5' cables included
  • Connectors available in two styles:
    • DB25 connectors, uses Rose UltraCable, supports USB
    • PC connectors, uses native connectors for keyboard, video, and mouse
  • Works with all PCs and most UNIX workstations
  • USB support on DB25 models (with UltraCables)
  • Supports wheel and serial mice
  • Select computer from front panel or from easy to use keyboard commands
  • Front panel LEDs show computer selected, power status, and activity
  • Powered by your computer, no external power supply required
  • Scan mode sequences through computers at adjustable rate
  • Non-volatile memory stores configuration settings
  • Made in USA

The Rose Vista Advantage

The Rose Vista Mini T-Series is intended for desktop applications. They are very small (3.2” W) and have very high resolution. They are the smallest Rose KVM switch.

Keyboard and Mouse: All Vista models support full emulation of keyboard and mouse. It works with major operating systems such as Windows, Linux, and UNIX running on workstations such as SGI, IBM RS/6000, HP 9000, Dec Alpha, and others. All models support PS/2, PS/2 wheel, or serial mice. This model does not support a physical serial mouse. When using the DB25 models with USB cables, you can use PC-USB, Apple-USB, or Sun-USB.

Video: All Vista models have very high resolution capability and support VGA video beyond 1600 x 1280 non-interlaced. Keyboard, mouse, and video signals can be driven up to 1000 feet using our CrystalView extenders.

Rose Vista Mini T-Series Switch Kit Specifications

  3.2" W x 4.2" D x .8" H / 1 lb.
8.1 W x 10.7 D x 20.3 H (cm) / .5 kg
Input Power Supply   Supplied by computers; optional power available
Video Resolution   1920 x 1440

  Video: HD 15 Female VGA Video
Keyboard: MiniDin-6F
Mouse: MiniDin-6F
CPU PC models: HD15F/MiniDin-6F/MiniDin-6F
DB25 models: DB25 Female

  Fully shielded, black painted steel with polyester graphic overlay panel

  Computer Select Switch: 1-8 (varies by model)
Status LED, shows keyboard-mouse activity

  Computer select LEDs 1-8 (varies by model)
Computer power LEDs 1-8 (varies by model)
Environmental   0°- 55°C, 0%-80% non-condensing relative humidity
Approvals   CE
