VDX UXGA & RS-232 CAT5 Receiver

VDX-RXS

$199.00

Discontinued
Recommended replacement: NTI ST-C5VRS-600
Alternative options: Contact Us

smartavi_madeinusa

The VDX Receiver allows the extension of high definition video and RS-232 control signals via a single CAT5 twisted pair cable up to 1,000 feet using a unique method of transparent data transfer.

Features

  • Uses easy to install, inexpensive CAT5/5e/6/7/8.
  • Output reaches up to 1,000 feet (300 m).
  • Supports high resolution clear video up to 1920x1200
  • HDTV compatible (720p, 1080i,1080p)
  • 300 MHz Bandwidth.
  • Sends high-resolution XVGA and RS232 signals.
  • Compatible with VGA, XGA, Sun, MAC and SGI
  • Sync Format / Polarity Preservation.
  • Bidirectional serial RS-232 (Tx/Rx) control.
  • High ground loop immunity.
  • Built-in lightning, power surge and transient protection.
  • Designated trimmer in the remote unit to compensate for cable length.
  • Compact metal case enclosure.
  • Remote units come with buffered outputs.

diagram

SmartAVI VDX Receiver Specifications

Mechanical
Weight0.1 lb. (0.3 kg.)
Power
Requirements5V DC @500mA
Connector5x2.1mm DC jack
Video
Bandwidth400 MHz
Analog Signal Level1 Volt
Impedance75 ohms
ConnectorHigh Density HD15
FormatVGA/SVGA/XGA/UXGA/
RGBH/RGBsB
SyncTTL horizontal SyncRange: 15 to 130 KHz Vertical Sync Range 30 to 120 Hz
RS232
ConnectionBi-directional Transmit Receive Only, RXD, TXD
System Cable
TypeCAT5 UTP EIA 568A
ConnectorRJ45
