8x8 DVI Matrix Switch with Scaler

VM5808D

$4,463.00$3,230.77
Save $1,232.23
FREE Shipping on orders over $100

The VM5404D includes seamless switching that employs an FPGA matrix architecture to ensure continuous video streaming, real-time control and stable signal transmission. With a built-in high-performance scaler, the VM5404D easily converts various input resolutions into a array of output resolutions, giving viewers the best image quality across all displays. The switch also integrates video wall functionality with an easy-to-use web GUI that lets you create 8 connection profiles for convenient layout customization.

Product Features and Benefits

  • 8x8 DVI I/O connections
  • Configuration and Control via pushbuttons / IR Remote Control
  • System Operation via bi-directional RS-232 serial controller / Browser Graphical User Interface (GUI) / Telnet
  • Extends IR transmission via IR extension cable
  • Built-in Scaler on each output port converts input resolutions into the display's native resolution, supports scaling 1920 x 1200 resolutions up or down
  • Seamless Switch - ATEN FPGA design unifies video formats to provide continuous video streams, real-time switching and stable signal transmissions
  • Video Wall - features up to 8 video wall profiles for custom screen layouts via point-n-click web GUI
  • EDID Expert - configures optimum EDID settings for smooth power-up, high-quality display and use of the best resolution across different screen
  • Firmware Upgradeable
  • Rack Mountable (1U Design)

Package Contains

  • 1x VM5808D 8 x 8 DVI Matrix Switch with Scaler
  • 1x Power Cord
  • 1x IR Remote Control
  • 1x IR Receiver
  • 1x Mounting Kit
  • 1x User Instructions
Video Input
Interfaces8 x DVI-D Female
Impedance100 Ohm
Max Distance1.8 m
Video Output
Interfaces8 x DVI-D Female
Impedance100 Ohm
Video
Max Data Rate6.75 Gbps (2.25 Gbps per lane)
Max Pixel Clock225 Mhz
ComplianceHDCP 1.4 Compatible
Max Resolutions1920 x 1200
Max DistanceUp to 5m
Control
RS-2321 x DB-9 Female. 19200 Baud Rate.
IR1 x Mini Stereo Jack Female
Ethernet1 x RJ-45 Female
Power
Connectors1 x 3-Prong AC Socket
Consumption120VAC, 34.1W; 230VAC, 34.4W
Environment
Operating Temperature32-122°F (0-50°C)
Storage Temperature-4-140°F (-20-60°C)
Humidity0-80% RH, Non-Condensing
Physical Properties
HousingMetal
Weight7.71 lbs. (3.50 kg)
Dimensions (L x W x H)17 x 10.22 x 1.73 in. (43.24 x 25.98 x 4.40 cm.)
UPC / EAN Barcode icon
UPC 672792006616
EAN 0672792006616
