DVI to Computer Graphics/Component/HDTV Video Format Converter

FC-32

$330.00
FREE Shipping on orders over $100

The FC-32 is a high-performance format converter for DVI-D signals. The unit converts (without scaling) a DVI-D input to a computer graphics or component video output on a 15-pin HD connector.

Features & Benefits

  • HDTV Compatible.
  • Max. Resolution - WUXGA & 1080p.
  • Computer Graphics Video or Component (HDTV) Selector Switch.
  • Compact DigiTOOLS - 3 units can be rack mounted side-by-side in a 1U rack space with the optional RK-3T rack adapter.
Product Use Diagram

Technical Specifications

Input1 DVI-D; 1.2Vpp on a Molex 24-pin (F) connector; DDC signal 5Vpp (TTL)
Output1 VGA or YPbPr on a 15-pin HD (F) connector; YPbPr is with bi-level sync
ResolutionUp to WUXGA; 1080p
ControlsSwitch for RGB/YPbPr selection
Power Consumption5V DC 570mA
Dimensions WxDxH4.20" x 4.07" x 1.72" (10.68cm x 10.35cm x 4.36cm)
Product Weight0.7 lbs (0.3 kg)
