Rose Electronics MultiVideo MPC-8U2V 8-Port, Dual Monitor KVM

MPC-8U2V

$1,899.00$1,661.63
Save $237.37
FREE Shipping on orders over $100

The Rose MultiVideo MPC-8U2V delivers keyboard command switching between different CPUs that are sending multiple video signals. With the rose MPC-8U2V a user can easily switch between eight computers to view 2 video outputs per CPU. Daisy chain MultiVideo units to support up to 64 CPUs.

The MPC-8U2V uses simple keyboard commands to switch between computers. The optional on-screen display (call 1-877-586-6654 for availability and pricing) allows switching from the streamlined highly customizable visual interface.

The MPC-8U2V's high resolution capabilities make it ideal for many diverse applications including financial trading, emergency call centers, television studios, medical imaging, video editing, process control, and CAD/CAM to name just a few.

Combine the MPC-8U2V with Rose's ViewLink or CrystalView extenders and extend the local console up to 10 km (approx. 6 miles) away.

Rose MultiView Application

Features and Benefits

  • 8 computers, each with 2 video ports
  • Video resolution up to 1600 x 1280
  • Integrated expansion for chaining units together supports up to 64 computers
  • PC-platform units support PS/2 and USB keyboard and mouse to computer
  • Optional advanced on-screen display (OSD) for configuration, computer selection, security, on-screen names, and screen savers (call 1-877-586-6654 for availability and pricing)
  • Switch computers from keyboard, front panel, optional OSD, or RS232 port
  • Scan mode switches through computers with adjustable rate
  • Easy to use keyboard shortcut switches computer or turns scan mode on/off
  • Supports HV sync, composite sync, and sync-on-green
  • Free firmware upgrades for product enhancements and new Software features available
  • Rack mount kits available in 19", 23", and 24" sizes
  • Made in USA



MPC-U2V Specifications

Mechanical
Width16.7 in. (42.4 cm.)
Height3.5 in. (8.9 cm.)
Depth4.85 in. (12.3 cm.)
Weight7 lbs. (1.8 kgs.)
Computer Connections8
Port SelectionKeyboard, Front Panel, RS232 Port or Optional OSD
Connectors
Console PortsDB25 Female
KVM PortsDB25 Female
PowerIEC 320 standard receptacle
RS232RJ 6 Conductor
Video PortsDB25

ControlsLighted Power On / Off Switch
Video Specifications
Bandwidth250 MHz
SyncAccepts HV, composite, and sync-on-green

IndicatorsLEDs: Power, 4-16 select, 4-16 CPU power
VideoVideo resolution up to 1600 x 1280
ApprovalsUL, cUL, TUV, CE
PowerAuto Switching, 90 - 240 VAC, 60 watts
Environment
Operating Temperature0-55C
Humidity5-80% RH, Non-condensing
Physical Properties
HousingElectro galvanized steel, black powder coated
