Rose Electronics 17in LCD, KVM Station w/touchpad

RV1-CKVT17

$2,499.00

Discontinued
Recommended replacement: Raloy RF117HD
Alternative options: Contact Us

Rose RackView (RV1-CKVT17)
The Rose RackView (RV1-CKVT17) offers the latest, most efficient way to organize and streamline your server rooms and multiple computers. The RackView (RV1-CKVT17) is a rack mountable KVM station neatly fitted in a 1U or 2U compact pull-out drawer. This easy-glide KVM station (RV1-CKVT17) contains a high-resolution TFT/LCD monitor, a tactile keyboard, and a high-resolution trackball or touchpad mouse. The Rose RackView (RV1-CKVT17) can be placed at any height within a standard 19" rack. This offers the operator the maximum in comfort and takes up a minimum amount of rack space. The 2U model will install in an 18" deep rack. The front panel conceals the unit when it is not in use.

Rose RackView (RV1-CKVT17) Features & Benefits:

  • The following model features are available:
    1U - 15" / 17" TFT/LCD high-resolution monitor
    2U - 15" TFT/LCD high-resolution monitor
    Tactile keyboard with separate numeric keypad
    Integrated trackball or touchpad mouse
    PS/2 connections
  • Built-in single or multiple user KVM switch options
  • Provides access to as many as 1,000 computers
  • Quick and easy rack mounting installation
  • Supports AT/XT, PS/2, and UNIX computers
  • Front panel conceals unit when it is not in use
  • Full size keyboard for typing comfort
  • Keyboard available in international variations
  • Monitor OSD allows for easy adjustments of color, brightness, contrast, position, and shape of the display
  • Front panel controls for quick adjustments
  • Easy-glide KVM drawer can be mounted at any height in a standard 19 inch rack

Rose RackView (RV1-CKVT17)
Rose RackView (RV1-CKVT17) Function Diagram

Rose RackView (RV1-CKVT17) Specifications:

Mechanical
Depth

15" models- 24"-37"
17" models- 24"-37"

Weight

15" models- 28 lbs
17" models- 28 lbs

Environmental PS/2 or USBUp to 1280 x 1024 @ 75Hz32°F - 122°F (0°- 50° C),
20%-80% non-condensing RH
Resolutions

PS/2 or USBUp to 1280 x 1024 @ 75Hz

Connectors
Video 15" and 17" models - HD15F
Keyboard PS/2 , Full size tactile keyboard with
separate numeric keypad
Mouse PS/2, Trackball or Touchpad
Standards
Colors 16.7 million
