1:2 Twisted Pair Line Driver & Distribution Amplifier

TP-105

The TP-105 and TP-105HD are line drivers and distribution amplifiers for twisted pair signals. They take a twisted pair input and distribute it to 2 identical twisted pair outputs.

Features & Benefits

  • Max. Resolution - WUXGA & 1080p (TP-105HD).
  • Twisted Pair Output - RJ-45 connectors.
  • Level (Gain) and EQ (Peaking) Controls.
  • System Range - Up to 100 meters (320ft).
  • Power Connect System - Only one unit in a system, the transmitter or the receiver needs to be connected to a power source when the devices are within 50m (150ft) of each other.
  • HDTV Compatible (TP-105HD).
  • Cable - UTP (unshielded twisted pair) or STP (shielded twisted pair) such as CAT 5.

Product Use Diagram

Product Specifications

Inputs1 RJ-45 connector
Outputs2 RJ-45 connectors
Max Output Level1.6Vpp
Max ResolutionWUXGA
Diff. Gain1.2%
Diff. Phase0.1Deg
K-Factor<0.1%
S/N Ratio69dB
ControlsEQ.: 0 to 4.4dB @50MHz; LEVEL: -5.5dB to 1.4dB
CouplingAC
Power Consumption12V DC; 220mA
Operating Temperature0° to 40°C (32° to 104°F)
Storage Temperature-40° to +70°C (-40° to 158°F)
Product Dimensions W, D, H4.72" x 2.81" x 0.96" (12.00cm x 7.15cm x 2.44cm)
Product Weight0.3 lbs (0.1kg)
