1:10 Computer Graphics Video over Twisted Pair Transmitter with Dual 15-pin HD Outputs


FREE Shipping on orders over $100

The TP-210 is a high-performance distribution amplifier for computer graphics video signals with resolutions up to and exceeding UXGA. It takes one input and provides ten twisted pair outputs plus two computer graphics video outputs on 15-pin HD connectors for local monitoring.

Features & Benefits

  • Max. Resolution - WUXGA & 1080p.
  • HDTV Compatible.
  • Sync Polarity Settings - H & V switches for improved display compatibility with the CAT 5 outputs.
  • System Range - Up to 100m (320ft) (twisted pair).
  • Cable - UTP (unshielded twisted pair) or STP (shielded twisted pair) such as CAT 5.
  • Power Connect System - A single connection to the transmitter or the receiver powers both units when the devices are within 150ft (50m) of each other.
  • Standard 19" Rack Mount Size - 1U. Rack "ears" included.

Product Use Diagram

Product Specifications

Inputs1 UXGA on a 15-pin HD (F) connector
Outputs2 UXGA on 15-pin HD (F) connectors; 10 twisted pairs on RJ-45 connectors
Max Output Level1.9Vpp/1.6Vpp
Max ResolutionWUXGA & 1080p
Diff. Gain0.03% (UXGA); 2.5% (CAT 5)
Diff. Phase0.05Deg (UXGA); 0.5Deg (CAT 5)
K-Factor<0.05% (UXGA); <0.05% (CAT 5)
S/N Ratio73.6dB (UXGA); 68.5dB (CAT 5)
ControlsLevel: -9.6dB to 2.4dB; EQ. @50MHz: 0 to 37.6dB (with TP-120 receiver)
Power Consumption100 to 240V AC; 50/60Hz; 54VA
Operating Temperature0° to 40°C (32° to 104°F)
Storage Temperature-40° to +70°C (-40° to 158°F)
Product Dimensions W, D, H19" x 7.20" x 1U (43.6cm x 18.30cm 4.36cm)
Product Weight3.5 lbs (1.6kg)
