4x4 4K@60Hz HDMI Matrix Video Switch with Scaler
VM6404H
4K is the next generation of image quality for high definition video. 4K delivers eight million pixels which is four times as much detail as 1080p Full HD resolutions. ATEN's VM6404H 4K HDMI Matrix Switch with Scaler is compatible with the two latest 4K video resolution standards: 3840 x 2160 and 4096 x 2160. The VM6404H provides powerful HD processing to produce 4K resolutions across four displays with crystal clear images.
The VM6404H supports 4K@60Hz, HDMI 2.0* and HDCP 2.2 and features seamless switching that employs a FPGA matrix architecture that ensures continuous video streams, real-time control and stable signal transmissions. With a built-in high-performance scaler, the VM6404H easily converts various input resolutions into various output display resolutions, giving viewers the best video and picture quality across all displays. The switch integrates video wall functionality with an easy to use web GUI that lets you create 8 connection profiles that can be customized into different video wall layouts.
- 4x4 HDMI input/output connections
- HDMI 2.0 supports 3840 x 2160 @30 Hz (4:4:4), 3840 x 2160 @60 Hz (4:2:0), 4096 x 2160 @ 30Hz (4:4:4), 4096 x 2160 @ 60 Hz (4:2:0) resolutions
- Front-Panel configuration via LCD display / pushbuttons / IR remote control
- System Operation via bi-directional RS-232 serial controller / Ethernet / Telnet / IR Remoter Control / front-panel pushbuttons / GUI
- Built-in Scaler on each output port converts input resolutions into the display's native resolution, supports scaling 4K resolutions up or down
- Seamless Switch - ATEN FPGA design unifies video formats to provide continuous video streams, real-time switching and stable signal transmissions
- Video Wall - Features up to 8 video wall profiles for custom screen layouts via point-n-click web GUI
- EDID Expert - configures optimum EDID settings for smooth power-up, high-quality display and use of the best resolution across different screens
- Firmware upgradable
- Rack-mountable (1U design)
* Note: If Seamless Switching is enabled, the video output will not display 3D, Deep Color or interlace (i.e., 1080i) resolutions. To make these features available, you must disable Seamless Switching.
This VM6404H package includes: Power Cord, IR Remote Control, IR Receiver, Mounting Kit and User Instructions.
| Mechanical | |
| Height | 1.73 in. (4.40 cm.) |
| Width | 13.87 in. (35.23 cm.) |
| Depth | 17.02 in. (43.24 cm.) |
| Weight | 11.07 lbs. (5.02 kg.) |
| Rack Units | 1U |
| Power | Connector: 1 x 3-prong AC Socket Input Rating: 100-240 VAC; 50-60Hz; 1.0A Consumption: 120VAC, 47.6W; 230VAC, 47.5W |
| Control | |
| IR | 1 x Mini Stereo Jack Female (Black) |
| RS232 | Connector: 1 x DB-9 Female (Black) Baud Rate: 19200, Data Bits: 8, Stop Bits: 1, Parity: No Flow Control: No |
| Ethernet | Connector: 1 x RJ-45 Female |
| Video | |
| Video Input | Interface: 4 x HDMI Type A Female (Black) Impedence: 100ohm Max Distance: 5.9 feet (1.8 meters) |
| Video Output | Interface: 4 x HDMI Type A Female (Black) Impedence: 100ohm Max Distance: 49.21 feet (15 meters) |
| Max Data Rate | 10.2 Gbps (3.40 Gbps per lane) |
| Max Pixel Clock | 340 MHz |
| Compliance | HDMI (3D, Deep Color, 4K) HDCP 2.2 Compatible Consumer Electronics Control (CEC) |
| Max Resolutions | Up to 3840 x 2160 @30 Hz (4:4:4) 3840 x 2160 @60 Hz (4:2:0) 4096 x 2160 @ 30Hz (4:4:4) 4096 x 2160 @ 60 Hz (4:2:0) |
| Max Distance | 49.21 feet (15 meters) |
| Enviroment | |
| Operating Temp | 32 - 122°F (0 - 50°C) |
| Storage Temp | -4 - 140°F (-20 - 60°C) |
Humidity | 0 - 80% RH, Non-condensing |
UPC 672792006258
EAN 0672792006258
