1:2 Computer Graphics Video & Stereo Audio Distribution Amplifier

VP-200AK

$365.00
FREE Shipping on orders over $100

The VP-200AK is a high-performance distribution amplifier for computer graphics video signals, with resolutions up to and exceeding UXGA, and unbalanced stereo audio. It takes a computer graphics video and stereo audio input and outputs two computer graphics video, two balanced, and two unbalanced stereo audio signals.

Features & Benefits

  • High Bandwidth - 510MHz (-3dB).
  • HDTV Compatible.
  • Audio Outputs - Simultaneous balanced and unbalanced stereo.
  • EQ (Peaking Control) Audio Level (Gain) Controls.
  • Kr-isp Advanced Sync Processing - Ensures compatibility with a wide range of computers (even if the sync level is too low) by restoring the sync signal waveform. Kr-isp advanced sync processing can be enabled or disabled via internal switches.
  • ID Bit Control.

Product Use Diagram

Product Specifications

Inputs1 UXGA on a 15-pin HD (F) connector; 1 unbalanced stereo audio on a 3.5mm mini jack
Outputs2 UXGA on 15-pin HD (F) connectors; 2 unbalanced stereo audio on 3.5mm mini jacks; 2 balanced stereo audio on detachable 5-pin terminal blocks
Max Output LevelVideo: 2.0Vpp; Audio: 7.2Vpp
BandwidthVideo: 510MHz; Audio: >100kHz
Diff. Gain0.55%
Diff. Phase0.10Deg
K-Factor<0.05%
S/N RatioVideo: 72.5dB @5MHz; Audio: 82dB (balanced); 88dB (unbalanced)
ControlsEQ: 0dB to 4.7dB @50MHz
Audio THD + Noise0.005% @1kHz (unbalanced and balanced)
Audio 2nd Harmonic0.003% (unbalanced); 0.001% (balanced)
Power Consumption5V DC; 120mA
Operating Temperature0° to 40°C (32° to 104°F)
Storage Temperature-40° to +70°C (-40° to 158°F)
Product Dimensions W, D, H4.72" x 2.81" x 0.96" (12.00cm x 7.15cm x 2.44cm)
Product Weight0.4 lbs (0.2kg)
