The VP-2K is a high-performance distribution amplifier for computer graphics video signals, with resolutions up to and exceeding UXGA, and unbalanced stereo audio signals. The unit distributes one input signal to two identical outputs.
Features & Benefits
- High Bandwidth - 380MHz (-3dB).
- HDTV Compatible.
- Kramer Kr-isp Advanced Sync Processing - Ensures compatibility with a wide range of computers (even if the sync level is too low) by restoring the sync signal waveform. Kr-isp advanced sync processing can be enabled or disabled.
- Level (Gain) & EQ (Peaking) Controls.
- Audio Level Control.
- Selectable AC/DC Coupling.
- ID Bit Control.
Product Specifications
Inputs | 1 UXGA on a 15-pin HD (F) connector; 1 unbalanced stereo audio on RCA connectors |
Outputs | 2 UXGA on 15-pin HD (F) connectors; 2 unbalanced stereo audio on RCA connectors |
Max Output Level | Video: 2.2Vpp; Audio: 6.8Vpp |
Bandwidth | Video: 380MHz; Audio: >100kHz |
Diff. Gain | 0.03% |
Diff. Phase | 0.03Deg |
K-Factor | <0.05% |
S/N Ratio | Video: 73dB; Audio: 89dB |
Coupling | Video: DC/AC selectable; Audio: Input AC, Output DC |
Controls | UXGA: Level: -1.1dB to 6.5dB; EQ.: 0dB to 5.3dB@50MHz; Audio Level: -50dB to 6.2dB; ID BIT switch; Coupling switches; Sync processing (normal or Kr-isp) |
Audio THD + Noise | 0.064% |
Audio 2nd Harmonic | 0.002% |
Power Consumption | 5V DC; 150mA |
Operating Temperature | 0° to 40°C (32° to 104°F) |
Storage Temperature | -40° to +70°C (-40° to 158°F) |
Product Dimensions W, D, H | 6.4" x 4.2" x 1.7" (16.2cm x 10.7cm x 4.4cm) |
Product Weight | 1.5 lbs (0.7kg) |
