1:5 Computer Graphics Video Twisted Pair Receiver & Distribution Amplifier

VP-5R

$520.00
FREE Shipping on orders over $100

The VP-5R is a high-performance distribution amplifier for computer graphics video signals on a twisted pair cable. It takes one twisted pair input and distributes the signal to five identical computer graphics video outputs on 15-pin HD connectors.

Features & Benefits

  • Power Connect System - A single connection to the VP-5R powers both transmitter and receiver when the devices are within 150ft (50m) of each other.
  • Max. Resolution - WUXGA & 1080p.
  • HDTV Compatible.
  • Twisted Pair Connectors - RJ-45 connectors.
  • Level (Gain) and EQ (Peaking) Controls.
  • System Range (CAT 5) - Up to 100m (320ft).
  • Cable - UTP (unshielded twisted pair) or STP (shielded twisted pair) such as CAT 5.
  • High Bandwidth (15-pin HD) - 445MHz (-3dB).

Product Use Diagram

Product Specifications

Inputs1 twisted pair on an RJ-45 connector
Outputs5 UXGA on 15-pin HD connectors
Max Output Level1.4Vpp
Max ResolutionWUXGA & 1080p
Diff. Gain3.4%
Diff. Phase0.05Deg
K-Factor<0.05%
S/N Ratio74dB
ControlsLevel: -8.2dB to +4.3dB; Line EQ.: 0 to +30dB; Out EQ.: 0 to +8.6dB
CouplingAC
Power Consumption230V AC; 50/60Hz; (115V AC USA) 9.2VA
Operating Temperature0° to 40°C (32° to 104°F)
Storage Temperature-40° to +70°C (-40° to 158°F)
Product Dimensions W, D, H8.45" x 6.42" x 1.72" (21.46cm x 16.30cm x 4.36cm)
Product Weight2.8 lbs (1.3kg)
