1:8 Computer Graphics Video Distribution Amplifier

VP-8K

$675.00
FREE Shipping on orders over $100

The VP-8K is a high-performance distribution amplifier for computer graphics video signals with resolutions up to and exceeding UXGA. It takes one input, provides correct buffering and isolation, and distributes the signal to eight identical outputs.

Features & Benefits

  • High Bandwidth - 370MHz (-3dB).
  • HDTV Compatible.
  • Selectable Sync Input Impedance - 75Ω (video), 510Ω (Graphics/TTL).
  • Desktop Size - Compact size. 2 units can be rack mounted side-by-side in a 1U rack space with the optional RK-1 adapter.
  • Kr-isp Advanced Sync Processing - Ensures compatibility with a wide range of computers (even if the sync level is too low) by restoring the sync signal waveform. Kr-isp advanced sync processing can be enabled or disabled.

Product Use Diagram

Product Specifications

Inputs1 UXGA on a 15-pin HD (F) connector
Outputs8 UXGA on 15-pin HD (F) connectors
Max Output Level2.2Vpp
Diff. Gain0.05%
Diff. Phase0.05Deg
K-Factor<0.05%
S/N Ratio73dB
ControlsTTL/ANALOG switch (on the rear panel)
CouplingDC
Power Consumption5V DC; 390mA
Operating Temperature0° to 40°C (32° to 104°F)
Storage Temperature-40° to +70°C (-40° to 158°F)
Product Dimensions W, D, H8.45" x 6.42" x 1.72" (21.46cm x 16.30cm x 4.36cm)
Product Weight2.0 lbs (0.9kg)
