4-Port HDMI Input Board Module


FREE Shipping on orders over $100

The VM7804 4-Port HDMI Input Board is offers an easy way to route any of 4 audio/video sources to any of 4 displays, in combination with an ATEN Modular Matrix Switch.

The VM7804 also supports HDMI audio can be extracted and stereo audio that can be embedded.


  • Superior video quality - HDTV resolutions of 480p, 720p, 1080i and 1080p (1920 x 1080)
  • HDMI (3D, Deep Color); HDCP 1.4 Compatible
  • Built-in scaler on each output port to support the scaling function for different video Resolutions
  • Consumer Electronics Control (CEC) support
  • EDID Expert - selects optimum EDID settings for smooth power-up and the highest quality display
  • Built-in EDID wizard - provides an easy way to customized EDID settings
  • Hot-swappable design for easy integration of I/O boards
  • Audio-enabled, HDMI audio can be extracted and stereo audio can be embedded


diagram model



Width 9.4  in. (23.8 mm.)
Depth13.9 in. (35.2 mm.)
Height .9  in. (2.28 mm.)
Weight1.2  lbs. (.55 kg.)
Operating Temperature0°C to 40°C
Storage Temperature-20°C to -60°C
Humidity0-80% RH non-condensing
Power DC5V, 7W
HDMI Out4 x HDMI Type A Female (Black)
Audio Out 4 x captive screw connector, 5 pole
UPC / EAN Barcode icon
UPC 672792005596
EAN 0672792005596
