Belkin 19" LCD Rackmount Console



Recommended replacement: Raloy RWX119
Alternative options: Contact Us

The Belkin F1DC102P-SR LCD Rack Console 1U enables system administrators to conveniently control racked servers from a single, secure, compact console. With its slim design, the Rack Console fits a standard 19-inch rack, ensuring clearance for the full extension of the LCD and keyboard. The Rack Console offers other advanced features such as a key-locking mechanism to prevent unauthorized access, and cable-management arms that organize console cables as the drawer extends and retracts. The Rack Console works with KVM switches from Belkin or other vendors and conveniently offers PS/2 platform support.

Belkin F1DC102P-SR Features:

  • Saves space with 1U 19" rack-mount drawer design
  • Includes a key-locking mechanism to prevent unauthorized access to console
  • Features grade-A, 19" LCD TFT active-matrix, color panel for high quality
  • Integrates compact, 106-key function keyboard, including numeric 10-key pad
  • Designed especially for 4-post racks
  • Features adjustable brackets for broadest rack compatibility and ease

Belkin F1DC102P-SR Package Includes:

  • 19" LCD Rack Console 1U
  • Bracket Kit
  • Bracket Screws
  • Belkin - f1dc102p-sr - BACK
    Belkin- 1DC102P-SR - Back View

    Belkin F1DC102P-SR Specifications:

    Height 19 in. (482.6 mm.)
    Width 23.6 in. (599.4 mm.)
    Depth 1.70 in.(43.18 mm.)
    Weight 34.7 lbs. (15.7kg)
    Operating Temperature 32° to 104° F (0° to 40° C)
    Storage Temperature -4° to 140° F (-20° to 60° C)
    Power Auto-Switching, 100 to 240VAC, 50 to 60Hz, 48-Watt
    Supported Hardware
    Keyboard/Mouse Connection PS/2
    Keyboard Type Laptop Type
    Mouse Type Touch Pad Style
    Operating Life of Keys 8 Million Cycles
    Hardware Specifications
    Display Type 19" LCD Active-Matrix Color


    Question: Pls advise the replaced product for the Belkin F1DC102P-SR which is discontinued.
    Answer: For replacement options, we would recommend either the Raloy RN119 ( or the Raloy RW119 (a href=''>
