VGA Video/Audio Extender via CAT5 - Extend to 300 ft.
ST-C5VA-300
Save $25.00
The XTENDEX Mini HDMI Extender transmits digital video and audio signals up to 164 feet (50 meters) using one CAT6/6a/7 cable. Each extender consists of a local unit that connects to an HDMI source and a remote unit that connects to an HDMI display.
Product Features and Benefits
- Ideal solution for digital signage applications.
- Supports local and remote VGA monitors.
- Supports resolutions to 1920x1440.
- Sharpest and clearest VGA quality over CAT5 of any manufacturer.
- Built-in surge protection.
- Stereo audio enabled.
- Integrated mounting brackets for easy surface/wall mounting.
- Use in-house CAT5/5e/6/6a phone wiring to locate a monitor remotely.
- Optional VESA mounting bracket is available for mounting the local or remote unit to the back of a flat panel monitor.
Package Includes
- One transmitter unit
- One receiver unit
- User Manual
| Local Unit | |
| Host Connection | Supports a PC, SUN, MAC or NTI switch with VGA video. Multiplatform support: Windows 2000/XP/Vista/7/8/10, Windows Server 2000/2003/2008/2012, Solaris, Linux, FreeBSD, and MAC OS 9/10. Male 15-pin HD connector for computer connection. Stereo audio support - 3.5 mm stereo plug |
| Local Access | Crisp and clear 1920x1440 video resolution. Female 15-pin HD connector for local VGA monitor. Optional stereo audio support - 3.5 mm stereo jack. |
| Remote Unit | |
| Resolution | Supports resolutions up to 1920x1440; dependent on extension length |
| Connection | Female 15-pin HD connector. 3.5 mm stereo audio connection |
| Power | |
| Local Unit | 110 or 220 VAC at 50 or 60 Hz via AC adapter (included) |
| Remote Unit | Powered from local unit via CAT5/5e/6/6a cable. |
| Consumption | 10W Local, Remote powered from local. |
| Mechanical | |
| Dimensions(WxDxH) | 3.5 x 3.1 x 1.2 in (89 x 79 x 30 mm) |
| Weight | 2.0 lbs. (0.90 kg) |
| Approvals | CE, RoHS |
| Warranty | Two Years |
| Environmental | |
| Operating Temperature | 32 to 100°F (0 to 38°C) |
| Storage Temperature | -20 to 140°F (-30 to 60°C) |
| Humidity | 17-90% Non-Condensing |
